Overview
The Parker L07531000C is a PNP sourcing switch assembly manufactured by Parker Schrader Bellows for industrial automation and motion control applications. PNP sourcing outputs provide current from a voltage source when activated, making this switch ideal for sinking input connections on controllers, PLCs, and servo drives. This position-indicating switch is designed for reliable pressure and position detection in pneumatic and hydraulic cylinder systems.
Key Features
- PNP sourcing output configuration for sinking input compatibility
- Suitable for pneumatic and hydraulic cylinder applications
- Industrial-grade construction from a trusted automation manufacturer
- Compact, integrated switch assembly design
- Designed for reliable position sensing and detection
Technical Specifications
While detailed voltage, current, and operating range specifications for the L07531000C were not available in current technical documentation, Parker’s standard PNP sourcing switches typically feature:
- Supply voltage: 10 to 30 VDC (typical for Parker electronic sensors)
- Output current: up to 100 mA (typical for PNP transistor outputs)
- Output type: PNP, normally open or normally closed configurable
- Response time: < 2.5 ms (typical for Parker electronic switches)
- Operating temperature: -30°C to +70°C (typical range)
- Enclosure rating: IP67 (common for industrial Parker switches)
Note: For exact specifications and pressure ratings, consult the manufacturer’s datasheet or contact a Parker distributor with the specific part number.
Typical Applications
- Pneumatic cylinder end-of-stroke position detection
- Hydraulic actuator limit switching
- Machine automation and motion control systems
- Industrial press and clamping applications
- Automated assembly and material handling equipment
Compatibility & Replacements
Compatible With
- Parker pneumatic and hydraulic cylinders
- PLC systems with sinking digital inputs
- Industrial servo drives supporting PNP sensors
- Automation controllers with 10–30 VDC input capability
- Systems requiring normally open or normally closed switching
Replaces / Drop-In Replacement For
The Parker L07531000C is a specific OEM part number. Verify compatibility with your system integrator before ordering, as direct replacements vary by application and cylinder type. Parker manufactures similar sourcing switch assemblies (L074910000, L07492000C) for comparable applications—consult technical documentation to confirm interchangeability for your specific installation.
Works With
- PNP sensor-compatible PLCs and industrial controllers
- Sinking digital input modules and I/O cards
- Parker actuators with standard M8 connector compatibility
- Standard 24 VDC industrial control circuits
- Discrete automation logic and motion control systems
