Overview
The Omron F10-S30R pattern matching sensor is a dedicated vision inspection device built for industrial automation systems requiring fast, accurate pattern recognition. This compact unit uses advanced pattern matching technology to detect and verify patterns, colors, and object shapes in real time, making it ideal for product verification, quality control, and sorting applications.
Key Features
- 8 Red LED Light Source — Dedicated illumination for high-contrast pattern detection (not suitable for red objects on white backgrounds)
- 25mm × 20mm Sensing Area — Precise and compact detection window for small component inspection
- Electronic Shutter — Adjustable exposure from 1/34,722 sec to 1/2,894 sec for optimal image capture
- Fixed Mounting Distance — 100 mm ±10 mm setting distance ensures consistent image quality
- 2-Meter Cable — Pre-installed sensor head cable for integration flexibility
- 18 VDC Power Supply — Operates from amplifier-provided 18 VDC ±10% for stable operation
Technical Specifications
- Part Number: F10-S30R
- Sensor Type: Pattern Matching Vision Sensor
- Power Supply: 18 VDC ±10% (provided from amplifier)
- Sensing Area: 25mm × 20mm
- Operating Distance: 100 mm ±10 mm
- Light Source: 8 red LEDs
- Shutter Speed Range: 1/34,722 sec to 1/2,894 sec (automatic)
- Cable Length: 2 meters
- Manufacturer: Omron
Typical Applications
- Product verification and quality assurance on automated lines
- Component orientation and position detection
- Color and pattern matching for sorting systems
- Package labeling verification and inspection
- Assembly line defect detection and product traceability
- Shape and edge detection for precision manufacturing
Compatibility & Replacements
Compatible With
- Omron F10 series amplifiers and controllers
- Industrial PLC systems supporting vision sensor inputs
- Standard industrial 18 VDC power supplies
- Automated production lines and conveyor systems
- Custom automation integrations with vision inspection requirements
Replaces / Drop-In Replacement For
- Omron F10-S30 (standard version without R designation)
- Verify compatibility with your system integrator before ordering for legacy systems
Works With
- Omron vision amplifier units and image processing controllers
- Industrial automation software supporting image analysis and pattern recognition
- Standard industrial networking protocols for PLC integration
- Discrete and analog I/O modules for sensor feedback
