Overview
The Omron DRT1-OD16 is a SYSMAC-series remote I/O terminal designed for distributed I/O expansion in industrial automation systems. This unit provides 16 transistor output points with PNP configuration and operates at 24 VDC, making it ideal for applications requiring remote signal switching and control relay logic implementation across network-connected nodes.
Key Features
- 16 transistor outputs (PNP configuration) for flexible remote switching
- 24 VDC nominal supply voltage with 0.3 AMP per terminal capacity
- DeviceNet (COMBOBUS/D) protocol for robust networked communication
- Compact DIN-rail compatible form factor for space-efficient installations
- Part of Omron’s proven SYSMAC industrial automation ecosystem
Technical Specifications
- Output Type: 16 Transistor Outputs (PNP)
- Supply Voltage: 24 VDC
- Output Current: 0.3 AMP per terminal
- Communication Protocol: DeviceNet (COMBOBUS/D)
- Input Point Current: 10 mA max per point at 24 VDC
- Physical Weight: 0.44 lbs (approximately 200g)
- Dimensions: 150 mm × 50 mm × 40 mm (5.9″ × 2.0″ × 1.6″)
- Product Series: Omron DRT1 Remote I/O Terminal
- Manufacturer Status: Discontinued by Omron
Typical Applications
- Remote signal switching for distributed I/O in manufacturing systems
- DeviceNet-networked solenoid valve and contactor control
- Machine-to-machine communication in multi-station assembly lines
- Replacing failed or aging I/O terminals in existing SYSMAC control systems
- Extending I/O capacity without adding physical controller modules
Compatibility & Replacements
Compatible With
- Omron SYSMAC CS1 series PLC controllers
- DeviceNet (COMBOBUS/D) industrial networks
- Omron CX-Programmer and SYSMAC engineering software platforms
- Standard 24 VDC industrial automation power supplies
Replaces / Drop-In Replacement For
- Omron DRT1-OD16-1 (variant with integrated connector option)
- Legacy Omron remote terminal units requiring 16-point PNP output expansion
Works With
- DeviceNet protocol networks and scanners
- Omron CX-Programmer software for configuration and diagnostics
- SYSMAC automation platforms and control strategies
- 24 VDC industrial I/O wiring standards and safety relay logic
