Overview
The Numatics 239-1384 is a G2-2 manual communication and configuration module designed for ASCO fieldbus-based pneumatic control systems. This 30-pin module serves as a configuration interface for G2-2 electronics platforms, enabling technicians and engineers to manually set up, commission, and diagnose fieldbus manifold nodes in industrial automation environments.
Key Features
- 30-pin manual configuration module for G2-2 fieldbus platform
- Supports multiple fieldbus protocols including Interbus-S
- Compatible with AKC and AKE pneumatic control manifolds
- Direct communication module configuration without external software
- Proven reliability in industrial pneumatic automation systems
Technical Specifications
- Part Number: 239-1384
- Series: G2-2 Fieldbus Electronics
- Connector Type: 30-pin
- Manufacturer: Numatics (ASCO)
- Module Type: Manual Communication/Configuration Module
- Fieldbus Support: All Protocols (including Interbus-S)
- Compatible Manifold Series: AKC, AKE
Typical Applications
- Pneumatic valve manifold commissioning and configuration
- Fieldbus node setup and diagnostics
- G2-2 electronics platform manual configuration
- Industrial automation system integration and troubleshooting
- Replacement for original or legacy manual communication modules
Compatibility & Replacements
Compatible With
- ASCO Numatics AKC pneumatic manifold series
- ASCO Numatics AKE pneumatic manifold series
- G2-2 fieldbus electronics platform
- Interbus-S and multi-protocol fieldbus systems
- Industrial pneumatic automation control systems
Replaces / Drop-In Replacement For
- Original Numatics 239-1384 units
- Legacy G2-2 manual configuration modules
- Other manual communication modules in G2-2 systems where part number 239-1384 is specified
Works With
- G2-2 fieldbus electronics platform (ASCO Numatics)
- Interbus-S protocol communication
- ASCO pneumatic valve control systems
- Industrial automation and process control networks
