Overview
The Nordson 322008 Saturn Precision Hot Melt Nozzle is a single-orifice straight nozzle designed for micro-precision adhesive application in industrial hot melt systems. The 322008 offers precise adhesive placement with its single-orifice straight bead design. It features a 0.008 in. (0.20 mm) orifice diameter, identified with a purple ring, and a 0.050 in. (1.3 mm) engagement length, also identified by a purple ring. This color-coded ring system enables rapid nozzle identification and changeover in production environments.
Key Features
- Manufactured with strict tolerances, the Saturn Nozzle delivers consistent bead placement and flow rates, reducing adhesive waste and improving product quality.
- Constructed from durable brass with a stainless-steel insert, this nozzle provides exceptional wear resistance for demanding industrial applications.
- Color-coded rings streamline nozzle selection and replacement, ensuring the correct configuration for optimal adhesive flow and application control.
- Single-orifice straight design optimized for detailed, high-precision work requiring exact adhesive placement
Technical Specifications
- Orifice Diameter: 0.008 in. (0.20 mm) – Purple Ring
- Engagement Length: 0.050 in. (1.3 mm) – Purple Ring
- Design Type: Single-orifice straight bead nozzle
- Body Material: Brass with stainless-steel insert
- Nozzle Series: Saturn Precision
- Weight: 0.05 lbs
Typical Applications
Nordson Saturn precision nozzles are commonly employed in precision dispensing in industrial applications across automotive, electronic, and medical spaces. The 322008’s ultra-fine 0.008″ orifice is ideal for applications requiring minimal adhesive flow and maximum placement accuracy, such as precision electronics assembly, small component bonding, and detailed medical device manufacturing.
Compatibility & Replacements
Compatible With
- SolidBlue S, ClassicBlue, Blue Series, MiniBlue, MiniBlue II, MiniBlue II LP, E-350, and E-380 applicators
- Nordson Saturn series hot melt adhesive dispensing systems
- Nordson standard modules and automatic/manual gun platforms
Replaces / Drop-In Replacement For
- Older 237XXX series nozzles
- Nordson 237208 (legacy part number equivalent)
- Includes cross-reference compatibility with 671XX101, A237-208, APNN8201, B208, CN1421, H237208, H322008, H322108, INFINITY NP-322008, MB208, NPS108, T2C72P8S, T3B20P8S, ZLA37A08, ZLS22F08
Works With
- Nordson hot melt adhesive dispensing systems
- All Nordson Saturn applicators (pencil modules, bench-top units, inline automated systems)
- Standard hot melt adhesive materials compatible with Nordson systems
