Overview
The Mitsubishi MR-J2M-10DU-PS is a compact, dual-axis AC servo amplifier from the MR-J2M series, designed for industrial automation applications requiring synchronized control of two independent axes. This amplifier provides 1.0 kW of power to each axis within a single, space-saving housing, significantly reducing installation footprint and system complexity compared to dual single-axis drives.
Key Features
- Dual-Axis Control — Manages two independent axes from a single amplifier, eliminating the need for separate drives and reducing cabinet space.
- Position, Speed & Torque Modes — Supports standard position, speed, and torque control modes, ensuring versatile and precise operation for compatible Mitsubishi AC servo motors.
- Compact Design — Delivers 1.0kW power per axis for synchronized and precise motion control in space-constrained industrial applications.
- Proven Reliability — The MR-J2M series combines the proven reliability and high performance of the standard MR-J2 series with the added benefit of integrated multi-axis control.
- Cost-Effective Solution — Often more economical than purchasing and installing two separate single-axis servo amplifiers.
Technical Specifications
None available in supplied data.
Typical Applications
- Robotic arms and gantry systems requiring coordinated two-axis motion
- Pick-and-place machinery with synchronized independent axes
- Assembly equipment in compact manufacturing environments
- Packaging and material handling systems
- CNC and precision automation platforms
Compatibility & Replacements
Compatible With
- Compatible Mitsubishi AC servo motors (typically HC-KF or HC-MF series)
- Mitsubishi motion controllers and CNC systems with SSCNET interface support
- Standard AC power supply (200 VAC, three-phase)
- Position, speed, and torque command inputs
Replaces / Drop-In Replacement For
- MR-J2M-10DU can be replaced with MR-J4-10A or MR-J4-10B for newer system designs
Works With
- Mitsubishi HC-KF series AC servo motors
- Mitsubishi HC-MF series AC servo motors
- SSCNET and general-purpose control interfaces
- Standard industrial AC power distribution systems
