Misumi Linear Ball Bearing Pillow Block LHBB30

The Misumi LHBB30 Linear Ball Bearing Pillow Block is engineered to provide precise linear motion for applications requiring a 30mm shaft diameter.

Key Features

• High-Quality Materials: Constructed with an outer cylinder made from 52100 bearing steel equivalent, ensuring durability and resistance to wear.
• Efficient Ball Recirculation: Features a single ball recirculating type design, facilitating smooth and consistent linear movement.
• Plastic Retainer: Equipped with a plastic retainer made from Duracon M90 equivalent, reducing noise and enhancing operational efficiency.
• Lubrication: Supplied with rust preventive oil, offering protection against corrosion and extending the bearing’s lifespan.

Specifications

• For Shaft Diameter: 30 mm
• Overall Length (L): 72 mm
• Basic Dynamic Load Rating: 1,570 N
• Basic Static Load Rating: 2,740 N
• Inner Contact Circle Tolerance (Negative Side): -0.01 mm

The Misumi LHBB30 is designed to deliver reliable performance in various industrial applications, ensuring smooth and precise linear motion.
