Overview
The Meteorlite 12-80VDC blue strobe light (model SY361005-B-LED) is a high-profile LED warning beacon engineered for industrial safety signaling. Manufactured by Superior Signals, this strobe light combines reliable flash technology with low current draw and extended operational life. The blue color makes it ideal for distinct visual alerting in warehouses, forklifts, manufacturing equipment, and mobile vehicles.
Key Features
- LED strobe technology with 100,000-hour operational life
- Low current draw—0.5 amp maximum at 1 watt for energy-efficient operation
- Polycarbonate clear lens with fiber-reinforced nylon base and rubber gasket
- High-profile design (2.56″ diameter × 5″ height) for maximum visibility
- Two-hole permanent mount on polyamide base for secure installation
- Single-flash mode at 75 ± 10 fpm (flashes per minute)
Technical Specifications
| Input Voltage | 12–80 VDC |
| Color | Blue |
| Current Draw | 0.5 amp maximum |
| Power Consumption | 1 watt |
| Flash Rate | 75 ± 10 fpm (single flash) |
| Dimensions | 2.56″ diameter × 5″ height (65 mm × 127 mm) |
| Base & Mount | Polyamide (PA) with 2-hole permanent mount |
| Lens Material | Polycarbonate |
| Certifications | SAE J1318 Class III, UL, CE, cUL approved |
| Part Number | SY361005-B-LED |
Typical Applications
- Forklift and material handling equipment warning lights
- Manufacturing machinery and assembly line alerts
- Mobile vehicle and dock safety beacons
- Industrial worksite status indication
- Emergency and hazard warning systems
Compatibility & Replacements
Compatible With
- 12–80 VDC power systems (including 12V, 24V, 48V, 72V applications)
- Hardwired permanent mount installations
- Forklift warning light systems
- Industrial machinery and equipment control circuits
Replaces / Drop-In Replacement For
- Meteorlite SY361005-B-LED 12-80VDC blue strobe (direct equivalent)
- Other Meteorlite 5 Series models (verify color and voltage specifications)
Works With
- 24 VDC and 12 VDC industrial power supplies
- PLC and safety relay circuits with DC voltage outputs
- Mobile equipment electrical systems
- Standard two-hole mounting brackets and fixtures
