Meru Networks PoE AP300 Dual Radio Access Point AP 320i

Overview

The Meru Networks AP320i is a dual-radio wireless access point designed for enterprise environments requiring high-performance, multi-standard 802.11 coverage. Built as an improved iteration of the AP300 series, the AP320i delivers both 802.11n and legacy 802.11a/b/g support in a low-profile design suitable for wall or ceiling mounting. Its integrated Power over Ethernet (PoE) capability simplifies deployment, eliminating the need for separate power runs.

Key Features

• Dual-radio design supporting 802.11a/b/g/n standards simultaneously
• Data rates up to 300Mbps with dual-band 2.4 GHz and 5 GHz operation
• Two integrated Orthogonal Array Beam Forming antenna systems with 2 dBi (2.4 GHz) and 3 dBi (5 GHz) gain
• 802.3af PoE and 802.3at power support for flexible deployment
• Auto-sensing Gigabit Ethernet interface (10/100/1000 Base-TX)
• Advanced security: WEP, TKIP, AES, WPA, WPA2, IEEE 802.1x, MAC filtering

Technical Specifications

• Wireless Standards: IEEE 802.11a, 802.11b, 802.11g, 802.11n
• Data Rate: Up to 300Mbps
• Frequency Bands: 2.402–2.485 GHz (2.4 GHz), 5.15–5.25 GHz, 5.725–5.825 GHz (5 GHz)
• Network Interface: 1× 10/100/1000 Base-TX Ethernet (RJ-45), 1× RJ45 console port
• Power Supply: 802.3af PoE or 802.3at PoE+, 5V DC alternative input
• Antenna: Dual integrated Orthogonal Array Beam Forming systems
• Operating Temperature: 0°C to 50°C (32°F to 122°F)
• Dimensions: 10.9″ W × 6.9″ H × 2.9″ D
• Status Indicators: 5 LEDs (power, Ethernet activity, 802.11 activity, 802.11 receive)

Typical Applications

• Enterprise office and campus wireless networks
• High-density 802.11n deployments requiring legacy device support
• Secure corporate networks with WPA2/802.1x authentication
• Facilities with PoE infrastructure already in place
• Distributed access point installations via Meru Virtual Cell architecture

Compatibility & Replacements

• IEEE 802.11a/b/g/n devices (client devices, roaming laptops, mobile devices)
• PoE-capable network switches and injectors (802.3af minimum, 802.3at recommended)
• Standard Ethernet networks (RJ45 Cat5e and above)
• Meru Virtual Cell wireless management architecture
• Enterprise security protocols: WPA, WPA2, 802.1x, RADIUS

• Meru AP300 (previous-generation platform)
• Direct compatibility with other AP320i units in mesh or controller-based deployments
• Verify specific network controller compatibility with your system integrator before ordering.

• IEEE 802.11 wireless protocols (a, b, g, n standards)
• WPA/WPA2 and 802.1x RADIUS authentication systems
• Meru Virtual Cell management (where applicable on supported firmware)
• Standard DHCP and static IP configuration
• Kensington MicroSaver Lock security slot for physical theft prevention
