Overview
The McGill MCYRR 6 SX is a CAMROL® yoke-mount cam follower bearing engineered for demanding mechanical automation and linear motion applications. This sealed metric bearing features a 6mm bore, 19mm roller diameter, and 11mm roller width with caged needle rolling elements. The bearing delivers 3730 N dynamic load and 4090 N static load capacity with a maximum rated speed of 15500 rpm and operating temperature range of -20 to 250 deg F.
Key Features
- Black oxide coating with LUBRI-DISC seal for protection and relubricatability
- Heavy-sectioned outer race design to withstand shock loading of cam follower operation
- Full-complement needle roller construction provides high radial load capacity
- Sealed enclosure with caged rolling elements for reliable sealing
- Crowned roller profile reduces edge loading and extends bearing life
- Chrome steel roller with black oxide finish for corrosion resistance
Technical Specifications
The McGill MCYRR 6 SX cam follower is designed for metric applications requiring precise yoke-mount alignment and sealed operation.
Typical Applications
McGill CAMROL full-complement needle bearings are used in mechanical automation or linear motion applications. Common uses include indexing mechanisms, automated machinery, conveyor systems, and industrial equipment requiring compact, sealed cam followers with minimal installation footprint.
Compatibility & Replacements
Compatible With
- Yoke-mount cam follower mechanical systems
- Linear motion and automation machinery
- Heavy-duty industrial indexing equipment
- Machinery requiring sealed, relubricatable bearings
Replaces / Drop-In Replacement For
- MCYRR 6 S (standard unsealed variant)
- OEM-specific yoke-mount roller assemblies requiring 6mm bore metric cam followers
Works With
- Standard metric yoke-mount stud designs
- Automated machinery control systems
- CRES CAMROL stainless steel versions are dimensionally interchangeable with standard CAMROL bearings
