Overview
The Mallory 1335L multi-deck rotary switch is a full-size industrial control component designed for applications requiring simultaneous switching of multiple circuits. This non-shorting switch provides 6 circuits organized across 3 sections, delivering reliable electrical isolation and precise positioning for equipment controls.
Key Features
- Non-shorting operation prevents unintended circuit bridging during position transitions
- 6 circuits across 3 independent sections for multi-function control
- 2 to 5 position selector range accommodates various logic configurations
- 2-inch shaft length with 1/4-inch diameter for standard panel mounting
- Durable construction suitable for industrial and commercial machinery
- Solder lug terminations for secure wire connections
Technical Specifications
- Switch Type: Full-size rotary multi-deck
- Configuration: 6 circuits, 3 sections
- Operating Mode: Non-shorting
- Position Range: 2 to 5 positions
- Shaft Diameter: 1/4 inch
- Shaft Length: 2 inches
- Termination: Solder lug
- Mounting Style: Panel-mount bushing
- Manufacturer: Mallory
- Part Number: 1335L
Typical Applications
The Mallory 1335L is suitable for equipment control, audio/radio equipment, test panels, mode selectors, and legacy industrial machinery where multi-circuit switching under light-to-medium load conditions is required. Its non-shorting design makes it ideal for logic circuits and safety-critical selector applications.
Compatibility & Replacements
Compatible With
- Industrial control panels and switchboards
- Audio and radio frequency equipment
- Test and measurement equipment
- Equipment requiring multi-position selection logic
- Light-load circuit switching (verify load ratings for your application)
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator or equipment documentation before ordering. The Mallory 1335L is a legacy component; direct replacements from current manufacturers may require mechanical or electrical adaptations.
Works With
- Solder-based assembly and hand-wiring techniques
- Vintage and legacy industrial control systems
- Equipment designed for Mallory rotary switch specifications
- Low-voltage AC/DC circuits (verify load specifications for your application)
