Overview
The L10-HM4 padlockable pistol-grip handle from Sprecher + Schuh is a durable panel-mount accessory designed for industrial control and disconnect switch applications. With IP66 environmental protection and a secure padlock provision, this handle ensures both functionality and safety in harsh industrial environments. The compact pistol-grip design provides ergonomic control while the padlock feature prevents unauthorized or accidental operation.
Key Features
- IP66-rated environmental protection—sealed against dust and water jets
- Padlockable design—lockable in off position, and on position with special modification
- Pistol-grip handle for intuitive, ergonomic operation
- Black powder-coated finish for corrosion resistance
- Compact form factor fits standard disconnect and motor-control enclosures
- Standard orientation with defeater mechanism
Technical Specifications
- Manufacturer: Sprecher + Schuh
- Part Number: L10-HM4
- Type: Padlockable Pistol-Grip Switch Handle
- Color: Black
- Protection Rating: IP66
- Length: 7-35/64 inches (192 mm)
- Width: 4-5/64 inches (103 mm)
- Height: 4-1/16 inches (103 mm)
- Weight: 0.93 lbs (0.42 kg)
- Locking Positions: Off position standard; on position with special modification
Typical Applications
- Industrial disconnect switches and safety switches
- Motor control centers (MCCs) and variable frequency drives (VFDs)
- Power distribution panels and equipment enclosures
- HVAC control systems and manufacturing equipment
- Any application requiring lockout/tagout (LOTO) capability
Compatibility & Replacements
Compatible With
- Sprecher + Schuh disconnect switches and motor starters
- Standard industrial panel-mount switch assemblies rated for pistol-grip handles
- NEMA 3, 3R, 12, and 4/4X enclosures
- IEC-rated disconnect and control systems
Replaces / Drop-In Replacement For
- OEM replacement for Sprecher + Schuh L10-HM4 original units
- Verify compatibility with your specific switch assembly before ordering
Works With
- 100A, 200A, and 400A class disconnect switches
- Standard NEMA/IEC industrial control panel layouts
- Lockout/tagout (LOTO) systems and safety interlocks
