Overview
The Keyence CV-070 color camera is a compact, high-performance vision component engineered for the CV-700 series industrial vision system. This 1/3-inch CCD camera delivers reliable color image capture with 350,000 pixels in progressive scan mode, making it ideal for machine vision inspection, quality control, and dimensional measurement tasks in automation environments.
Key Features
- 1/3-inch color CCD sensor with 350,000 pixels (progressive scan, square pixels)
- Adjustable electronic shutter (1/30 to 1/4000) for fast-moving objects and variable lighting
- Integrated 3-meter cable for direct CV-700 controller connection
- Compact design (~310g including cable) for space-constrained applications
- Purpose-built for CV-700 series compatibility with no additional adapters required
Technical Specifications
- Image Sensor: 1/3-inch color CCD, progressive scan
- Pixel Count: 350,000 pixels
- Cable Length: 3 meters
- Weight: Approximately 310g (including 3m cord)
- Electronic Shutter: 1/30, 1/50, 1/60, 1/100, 1/125, 1/250, 1/500, 1/1000, 1/2000, 1/4000 second
- Application Class: Industrial machine vision, color imaging
- Series: CV-700
Typical Applications
The CV-070 is commonly deployed in manufacturing and automation for:
- Color-based part identification and sorting
- Surface defect detection and quality inspection
- Component positioning and alignment verification
- Visual feedback for automated material handling systems
- Measurement and dimensional verification in high-speed production lines
Compatibility & Replacements
Compatible With
- Keyence CV-701 vision controller
- Keyence CV-751 vision controller
- Keyence CV-700 series vision systems
- C-mount lens systems (commercial-grade lenses with C-mount adapter)
Replaces / Drop-In Replacement For
The CV-070 is a direct OEM component for CV-700 series systems. Verify compatibility with your system integrator before ordering if adapting to non-standard setups.
Works With
- Keyence CV-700 series vision system software and controllers
- Standard industrial C-mount lenses (16mm, 25mm, 35mm, 50mm focal lengths common)
- Keyence illumination accessories and lighting solutions for CV-700 series
