Overview
The KEMET C0805C121F5GAC is a surface-mount ceramic capacitor designed for high-reliability electronic applications. This 120pF/50V device features a C0G dielectric material, providing exceptional temperature stability and low distortion. Manufactured by KEMET, a leading global supplier of electronic components, this capacitor meets industry standards for both commercial and industrial equipment.
Key Features
- Capacitance Value: 120 pF
- Voltage Rating: 50 VDC
- Case Size: 0805 (2.0mm × 1.25mm)
- Dielectric Type: C0G (NP0) – Temperature Compensating
- 5% Tolerance
- Low ESR and ESL for high-frequency performance
- Suitable for resonant circuits and precision timing applications
Technical Specifications
- Operating Temperature Range: -55°C to +125°C
- Voltage Derating: Standard IEC/EIA guidelines
- Packaging: Tape and Reel or Bulk Bag (standard KEMET configurations)
- RoHS Compliant
- Moisture Sensitivity Level: 1 (per IPC-A-610)
Typical Applications
- RF and high-frequency filtering circuits
- Resonant tank circuits
- Timing and oscillator circuits
- Coupling and bypass applications
- Precision measurement equipment
- Industrial instrumentation
Compatibility & Replacements
Compatible With
- All standard 0805 SMD footprint designs
- Lead-free assembly processes (RoHS-compliant)
- Industrial and commercial-grade PCB designs
Replaces / Drop-In Replacement For
Verify compatibility with your circuit design before ordering. KEMET C0805 series capacitors may have equivalent values from competing manufacturers (Murata, TDK, Samsung MLCC) at the same capacitance/voltage rating—consult your system integrator for qualified alternatives.
Works With
- Standard passive component assembly equipment
- Lead-free and RoHS manufacturing processes
- All EDA and PCB design tools (EAGLE, KiCAD, Altium, etc.)
