Overview
The ILME CHI-16 is a heavy-duty bulkhead-mount connector housing from ILME, a globally recognized leader in industrial connector solutions. This rectangular base unit features a C-TYPE configuration with size 77.27 designation, die-cast aluminum construction, and a patented stainless steel double-lever locking system. Designed for secure panel mounting in demanding industrial environments, the CHI-16 delivers consistent clamping force and maintains IP65 protection even after repeated mating cycles.
Key Features
- Die-cast aluminum body with polyamide handles for durability and lightweight operation
- Double stainless steel levers for secure, consistent clamping force
- IP65 protection rating maintained for 500+ mating cycles
- Rectangular base design optimized for bulkhead panel mounting
- C-TYPE series compatibility with standard industrial connector ecosystems
- Size 77.27 (77.5 × 27 mm insert center distance) for precise mechanical fit
Technical Specifications
- Mounting Type: Bulkhead panel mount
- Housing Material: Aluminum die-cast
- Handle Material: Polyamide
- Locking Mechanism: Stainless steel double levers
- Configuration: C-TYPE series, rectangular base
- Size Designation: 77.27
- Insert Center Distance: 77.5 × 27 mm
- Protection Rating: IP65 (rated)
- Mating Cycles: 500+
- Manufacturer: ILME
Typical Applications
- Semiconductor manufacturing equipment panel interconnect
- PCB processing machinery connector housings
- CNC and metalworking machine control systems
- Industrial automation control cabinets
- Heavy-duty panel-mount connector bases in manufacturing plants
- OEM equipment requiring sealed, durable bulkhead connectivity
Compatibility & Replacements
Compatible With
- ILME C-TYPE series connector inserts and contact systems
- Standard PG, Metric, and NPT cable gland openings
- Industrial automation and control panel installations
- Heavy-duty manufacturing and process control equipment
Replaces / Drop-In Replacement For
- Verify with your system integrator or equipment OEM documentation for exact replacement compatibility.
- This unit is compatible with other ILME CHI-16 configurations and may interchange with equivalent-sized industrial connector housings of the same C-TYPE series and 77.27 size designation.
Works With
- ILME C-TYPE inserts and connector modules
- Standard industrial control system architectures
- Panel-mount automation and machinery installations
- Heavy-duty manufacturing ecosystems requiring sealed connector housings
