Overview
The ifm Electronic EVC010 is a 4-pole M12 connection cable designed for industrial sensor and actuator connections. This 0.3-meter PUR-insulated patch cord features straight M12 socket to straight M12 plug configuration, making it ideal for factory automation, machine building, and hydraulic systems. The EVC010 delivers reliable signal transmission in harsh industrial environments with proven durability and oil resistance.
Key Features
- 4-Pole M12 Configuration — Straight socket to straight plug connectors for direct sensor-to-controller connections
- PUR Cable Construction — Polyurethane insulation rated for drag chains and flexible routing
- Gold-Plated Contacts — Ensures low contact resistance and corrosion protection for long service life
- Oil & Coolant Resistant — Silicone-free, halogen-free design resists hydraulic fluids and cutting coolants
- IP67/IP68/IP69K Protection — Rated for submersion, high-pressure wash-down, and harsh washdown environments
- Vibration & Shock Protection — Diecast zinc coupling nut with saw-tooth contoured locking mechanism prevents disconnection
- Tool-Free Installation — Permanent, reliable sealing without additional assembly requirements
Technical Specifications
| Connector Type | M12 Socket (Female) / M12 Plug (Male), Straight |
| Poles | 4 |
| Cable Length | 0.3 m (300 mm) |
| Cable Material | PUR (Polyurethane) |
| Insulation | Silicone-free, Halogen-free |
| Contact Plating | Gold-plated |
| Operating Voltage | < 250 V AC / < 300 V DC |
| Protection Rating | IP67 / IP68 / IP69K |
| Operating Temperature | -25 °C to +90 °C |
| Housing Material | TPU (Thermoplastic Urethane), Orange |
| Sealing | FKM (Fluorocarbon Rubber) |
| Weight | 42.5 g |
| Protection Class | II |
| Special Features | Vibration-shock resistant, mechanical O-ring protection, drag-chain suitable |
Typical Applications
- Factory Automation — PLC sensor input connections, proximity sensors, photo-electric sensors
- Machine Building — CNC machine tool sensor networks, spindle monitoring, coolant level sensing
- Hydraulic Systems — Pressure transducers, flow sensors in oil-filled environments
- Robotics & Motion Control — Joint feedback, end-of-arm tooling connections
- Food & Beverage Processing — Washdown-rated connections in sanitary environments
- Heavy Equipment & Mining — Vibration-resistant connections in shock-prone applications
Compatibility & Replacements
Compatible With
- All ifm M12 4-pole socket connectors and M12 4-pole plug connectors
- Siemens PROFINET M12 devices (4-pole variant)
- Rockwell CompactLogix, ControlLogix, and MicroLogix systems with M12 interface modules
- Mitsubishi and Omron PLC systems with M12 sensor input cards
- General-purpose industrial M12 4-pole sensor/actuator networks
Replaces / Drop-In Replacement For
- ifm Electronic EVC010 (exact match)
- Murrelektronik M12 4-pole patch cords (equivalent specification)
- Phoenix Contact M12 X-coded 4-pole cables (with voltage/protocol verification)
Works With
- Protocols: PROFIBUS, CANopen, Ethernet-based M12 interfaces
- Software Platforms: Studio 5000 (Rockwell), TIA Portal (Siemens), GX Works 2/3 (Mitsubishi)
- Communication Standards: M12 sensor/actuator networks, EtherNet/IP over M12
- ifm Product Ecosystems: ifm valve manifolds, pressure transducers, flow meters, proximity sensors
