Overview
The Hubbell HBL460P7W is an industrial-grade watertight pin and sleeve plug engineered for high-ampacity electrical connections in manufacturing, construction, and heavy-duty applications. Hubbell’s IEC 60309 Pin and Sleeve plugs are the highest performing products available, with the HBL series designed for the demanding North American market. Hubbell was the first and is still the only manufacturer of IEC 60309 devices in the USA. This cord-mount plug operates at 480V AC, 60A, with 3-pole 4-wire configuration and IP67 enclosure rating.
Key Features
- Rugged one-piece housing with thermoset polyester contact carrier that provides high resistance to electrical tracking
- Watertight construction with solid neoprene gaskets achieving IP67 rating for moisture and dust protection
- Zytel® 801 nylon housing construction for super tough application
- Heavy-duty external cord grip provides superior strain relief on conductors
- Certified for current interrupting at full rated current with 3,000V AC dielectric withstand voltage
- Reinforced thermoplastic polyester locking ring and stainless steel terminal screws
Technical Specifications
- 60A 3-phase delta 480V AC, 3-pole 4-wire grounding
- Operating temperature range: -40°C to 75°C maximum continuous
- Accommodates wire size 8–2 AWG
- Accepts 0.5–1.45 inch OD cable
- IP67 ingress protection rating
- Red composite construction, cord-mounted
- Pressure screw terminal connection
- 3,000V AC dielectric strength
Typical Applications
Ideal for fans, heaters, and pumps. Primarily serves industrial settings, including manufacturing plants and construction sites. Used in high ampacity connections. The watertight design makes it suitable for outdoor and wet environments where moisture protection is critical.
Compatibility & Replacements
Compatible With
- HBL460C7W connector and HBL460R7W receptacle
- HBL460B7W inlet
- IEC 60309-1 and 60309-2 standard pin and sleeve systems
- Industrial 480V 3-phase delta power distribution systems
Replaces / Drop-In Replacement For
- Pairs seamlessly with the HBL460C7W 60 amp 480-Volt Female Pin and Sleeve Connector
- Equivalent Leviton 460P7WLEV (480V 60A 3-phase)
- Marinco and Pass & Seymour 60A 480V 3-pole 4-wire plugs (where voltage and amperage match)
Works With
- IEC 60309-1 standard industrial connectors
- All 480V 3-phase wye or delta power systems
- North American industrial power distribution panels and equipment
- Heavy-duty portable power cord assemblies
