Overview
The Honeywell TC-ODA161 is a compact 16-channel digital AC output module engineered for integration into Honeywell distributed control systems. This module delivers pilot-duty switching for 120/240 VAC loads, making it suitable for controlling solenoid valves, motor starters, interposing relays, and industrial indicator lamps across process automation environments. The TC-ODA161 combines high-density I/O in a single slot with robust electrical isolation and surge protection.
Key Features
- 16 independently controlled AC output channels
- 120/240 VAC operation at 50/60 Hz
- 0.5 A pilot duty rating per channel
- Channel-to-channel galvanic isolation
- Integrated surge and inrush current protection
- Drop-in compatibility with Honeywell I/O rack chassis
- Field-installable terminal block connectors
Technical Specifications
- Output Voltage: 120/240 VAC
- Frequency: 50/60 Hz
- Current Rating: 0.5 A per channel (pilot duty)
- Number of Channels: 16 points
- Isolation: Galvanically isolated, channel-to-channel
- Protection: Surge and inrush current protection
- Connection: Terminal block interface
- Weight: 0.51 lbs
- Status: Discontinued by manufacturer
Typical Applications
- Solenoid valve control in process skids
- Motor starter and soft-start signaling
- Burner ignition and safety interlock sequences
- Conveyor and pump on/off control
- Pilot lamp and beacon indicators
- Compressor discharge and shutdown logic
- Industrial process automation cabinets
Compatibility & Replacements
Compatible With
- Honeywell C200 and C200E control processors
- Honeywell Experion PKS and Experion LS systems
- Honeywell TDC 3000 legacy distributed control systems
- Honeywell I/O chassis and rack assemblies
- Honeywell IOTA and termination panel systems
Replaces / Drop-In Replacement For
- Directly compatible with legacy TC-ODA161 installations
- Verify compatibility with your existing Honeywell I/O configuration before ordering
Works With
- Honeywell Control Builder configuration software
- Honeywell field termination and IOTA assemblies
- Standard 24 VDC field power distribution
- Honeywell process automation frameworks
