<h2>Overview</h2>
<p>The <strong>Honda MR-50LW+</strong> is a 50-position rectangular connector assembly featuring a durable plastic backshell designed for industrial and control system applications. This connector provides dual-purpose vertical and horizontal mounting configurations, making it suitable for both panel-mount and cable-mount scenarios in compact machinery and control enclosures.</p>
<h2>Key Features</h2>
<ul>
<li>50-position pin configuration for high-density signal routing</li>
<li>Dual-purpose vertical and horizontal mounting options</li>
<li>Dual screw and spring lock mechanism for vibration resistance</li>
<li>Dust-proof construction with excellent environmental protection</li>
<li>Integrated ø16mm conduit clamp for secure cable management</li>
<li>Compact design optimized for space-constrained installations</li>
</ul>
<h2>Technical Specifications</h2>
<ul>
<li><strong>Pin Count:</strong> 50 positions</li>
<li><strong>Voltage Rating:</strong> 300 VAC</li>
<li><strong>Current Rating:</strong> 3 A per pin</li>
<li><strong>Case Type:</strong> Plastic backshell, dual-purpose vertical/horizontal</li>
<li><strong>Mounting:</strong> Vertical and horizontal configurations</li>
<li><strong>Conduit Connector:</strong> ø16mm with integrated clamp</li>
<li><strong>Dimensions:</strong> 73.5 × 66.1 × 20 mm</li>
<li><strong>RoHS Compliant:</strong> Yes</li>
<li><strong>Country of Origin:</strong> Japan</li>
</ul>
<h2>Typical Applications</h2>
<ul>
<li>Industrial control panels and machine tool interfaces</li>
<li>Servo drive and motion control system interconnects</li>
<li>Multi-signal distribution in compact enclosures</li>
<li>Legacy equipment retrofit and maintenance replacements</li>
<li>High-density signal routing in manufacturing systems</li>
</ul>
<h2>Compatibility & Replacements</h2>
<h3>Compatible With</h3>
<ul>
<li>Honda MR series connector ecosystem</li>
<li>Standard industrial control cabinets and enclosures</li>
<li>Cable assemblies with 50-pin mating interfaces</li>
<li>Legacy manufacturing and test equipment</li>
</ul>
<h3>Replaces / Drop-In Replacement For</h3>
<ul>
<li>Honda MR-50LW (earlier variant without “+” designation)</li>
<li>Verify compatibility with your system integrator before ordering for legacy equipment.</li>
</ul>
<h3>Works With</h3>
<ul>
<li>Standard 50-position rectangular connector pinouts</li>
<li>Industrial control systems requiring multi-pin distribution</li>
<li>Manufacturing equipment using Honda MR series interfaces</li>
<li>Cable and harness assemblies with 50-contact specifications</li>
</ul>
