Overview
The Hoffman C-CS6IJRLG intermediate joint pendant arm is a structural connector designed for Hoffman Compact Suspension System pendant arm assemblies. This component joins two horizontal tubes together to extend overall arm length while adding a pivot point for directional adjustment. It joins two horizontal tubes together for a longer length and creates a pivot, making it essential for flexible HMI and control panel mounting applications where cable and power cord routing requires adjustable positioning.
Key Features
- Rotates 360-degree with limit stop for multi-directional adjustment
- Includes access plates for easy wire installation
- Cast or steel construction depending on series size
- RAL 7035 light-gray polyester powder paint finish
- Mounts directly to pendant tube assemblies with provided setscrews
Technical Specifications
The C-CS6IJRLG is part of the Hoffman Compact Series pendant arm system. Use of the intermediate joint reduces pendant arm load capacity by 43 percent. This reduction accounts for the additional pivot point and must be factored into system design calculations. The unit includes all necessary installation hardware and gasket components for secure attachment to standard pendant tubes.
Typical Applications
- HMI (Human Machine Interface) panel arm suspension systems
- Industrial control cabinet pendant mounting
- Overhead cable and power cord routing
- Workstation console arms requiring multi-axis adjustment
- Manufacturing and process control environments
Compatibility & Replacements
Compatible With
- Hoffman Compact Suspension System pendant arm assemblies
- Hoffman Compact Series 2 (45 x 60 mm) tube systems
- Hoffman Compact Series 4 (80 x 80 mm) tube systems
- Standard HMI mounting brackets and pendant platforms
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator or Hoffman technical support before ordering to confirm exact model compatibility and load capacity requirements for your specific application.
Works With
- Hoffman pendant arm tubes and assemblies
- Standard industrial cable management and routing systems
- HMI platform mounting systems
- nVent Hoffman Compact Series suspension components
