Overview
The Hubbell HBL8352C is a heavy-duty, industrial-grade angled male plug designed for 50A power distribution at 120/208V three-phase AC. This 4-pole, 4-wire (4P4W) connector meets NEMA 18-50P specifications and is UL certified for safe, secure electrical connections in industrial automation, manufacturing control systems, and commercial power applications.
Key Features
- 50A rated capacity at 120/208V three-phase AC
- 4-pole, 4-wire (4P4W) configuration with grounding
- Angled design for space-constrained installations
- Industrial nylon construction for durability and impact resistance
- UL certified for safety and compliance
- RoHS compliant materials
Technical Specifications
- Part Number: HBL8352C
- Manufacturer: Hubbell Wiring Device-Kellems
- Voltage Rating: 120/208V AC, 3-phase
- Amperage: 50A
- Configuration: 4-pole, 4-wire (4P4W)
- Connector Type: Male plug (angled)
- NEMA Rating: 18-50P
- Material: Industrial-grade nylon
- Certifications: UL listed, RoHS compliant
- Operating Temperature: –40°C to 75°C (maximum continuous)
Typical Applications
- Industrial automation and control panel connections
- Three-phase motor and equipment power distribution
- Manufacturing and facility electrical systems
- Heavy-duty commercial installations
- Machine tool and production line power feeds
- Data center and facility power management
Compatibility & Replacements
Compatible With
- NEMA 18-50R receptacles and outlets
- Three-phase 120/208V AC distribution systems
- Industrial electrical panels and disconnects
- Heavy-duty power distribution equipment
Replaces / Drop-In Replacement For
The HBL8352C is the angled male plug version in Hubbell’s 18-50P product line. Verify compatibility with your specific system integrator or electrical designer before ordering to ensure proper mating receptacle and wiring gauge compatibility.
Works With
- NEMA 18-50P rated receptacles
- Copper and aluminum conductor wirings (10, 8, 6, 4 AWG)
- Industrial PLC and motor control systems
- Three-phase power distribution cabinets
