Overview
The Harting 09300240408 is a Han Split Hood 24 B connector housing designed for heavy-duty industrial automation and control applications. This two-piece split hood provides panel-mount connectivity for Han 24 B rectangular shell connectors, delivering reliable mechanical and electrical protection in demanding environments.
Key Features
- Dual-lever locking mechanism — Ensures secure connection with high mechanical strength and vibration resistance
- IP65 protection — Dust-tight and water-resistant rating for harsh manufacturing and outdoor installations
- Four cable entry points — Integrated cable glands for organized cable management and strain relief
- Split-hood design — Two-piece construction simplifies field installation and maintenance without disconnecting all cables
- Polycarbonate body with metal inserts — Combines lightweight construction with durability and vibration damping
- RoHS compliant — Meets environmental and regulatory standards for global deployment
Technical Specifications
- Part Number: 09300240408
- Product Series: Han B
- Shell Size: 24B (rectangular)
- Cable Entries: 4
- Locking Type: 2-lever
- Housing Material: Polycarbonate body with metal components
- External Depth: 120 mm
- Weight: 0.0532 kg
- Protection Rating: IP65
- RoHS Compliant: Yes
Typical Applications
- Industrial automation control panels and enclosures
- Manufacturing equipment requiring vibration-resistant connectors
- Outdoor and washdown environments needing IP65 protection
- Heavy machinery and production line installations
- Panel-mounted connector assemblies for power and signal distribution
- Cable management in harsh industrial settings
Compatibility & Replacements
Compatible With
- Harting Han 24 B rectangular shell connectors
- Han 24 B inserts and base housings
- Industrial automation control systems using Han B series interfaces
- Heavy-duty connector assemblies (rectangular 24B shell)
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator or equipment documentation before ordering, as split hood compatibility depends on your specific connector base and insert configuration.
Works With
- Harting Han modular connector system
- Han B series inserts (contact and non-contact types)
- Standard DIN 43650 panel cutouts (24B rectangular)
- M20/M25 cable entry glands (integrated)
