Overview
The Habasit MAM-04H 50mm x 1170mm belt is a precision-engineered machine tape built for light to medium-duty conveyor and material transport applications. This modular belt features dual-sided abrasion resistance, exceptional elasticity, and consistent grip properties—making it a drop-in solution for feeder systems, letter sorting equipment, and paper handling machinery commonly found in manufacturing, postal, and packaging environments.
Key Features
- Abrasion-resistant construction on both running and pulley sides for extended service life
- Elastic and dimensionally stable polymer design minimizes slippage and maintains precision alignment
- Wide operating temperature range from -20°C to +60°C for climate-controlled or ambient facilities
- Antistatic capable material suitable for electrostatic-sensitive applications
- Quick-change jointing compatible with Flexproof and Quickmelt joining methods
Technical Specifications
- Width: 50 mm
- Length: 1170 mm
- Thickness: 1.5 mm
- Belt weight: 1.4 kg/m²
- Tensile force (8% static): 2.6 N/mm (15 lbf/in)
- Tensile force (8% relaxed): 1.8 N/mm (10 lbf/in)
- Operating temperature: -20°C to +60°C (-4°F to +140°F)
- Material: Polyamide or polyester blend with elastomer backing
- Seamless manufacturing width: Up to 1140 mm
Typical Applications
- Mail and document sorting systems
- Paper handling and folder belts
- Feeder systems for light industrial machinery
- Letter transport conveyors
- Sheeter and crosscutter operations
- Material handling on automated assembly lines
Compatibility & Replacements
Compatible With
- Modular conveyor systems using standard pulley diameters (consult application-specific requirements)
- Equipment designed for belts 50mm wide and 1140-1170mm circumference
- Systems requiring low-profile, high-precision belting
Replaces / Drop-In Replacement For
- Habasit MAM-04H belts in equivalent dimensions and configurations
- Direct replacement for OEM systems specifying Habasit MAM-04H 50×1170 belting
- Other manufacturers’ equivalent 50mm machine tape belts (verify pulley compatibility before ordering)
Works With
- Flexproof joining method (8×30 pin configuration)
- Quickmelt adhesive joining for field splicing
- Habasit guide rails (e.g., GR 1/2 for 50mm belts)
- Standard mechanical pulley and drive systems
