Overview
The AVC C5010T12L is a compact 12VDC cooling fan engineered for efficient thermal management in a wide range of industrial electronics and electrical enclosures. With its ball bearing construction and low power consumption, this fan delivers reliable long-term operation in demanding thermal control applications. The AVC C5010T12L is a popular choice for equipment cooling where dependable airflow and durability are essential.
Key Features
- 12VDC rated voltage with 0.15A low current draw—ideal for battery and low-voltage industrial systems
- Ball bearing construction for extended operational life and reduced maintenance
- Compact 50mm × 50mm × 10mm footprint fits tight mounting spaces
- 5200RPM speed delivers 12.78 CFM airflow at just 30.5 dB noise level
- Three-wire connector includes integrated RPM sensor for monitoring
- Low power consumption (1.2W) minimizes thermal load on power supplies
Technical Specifications
The AVC C5010T12L meets the cooling demands of servers, enclosure fans, and thermal management systems with stable performance characteristics:
- Input Voltage: 12VDC
- Current Draw: 0.15A
- Power Consumption: 1.8W maximum
- Speed: 5200 RPM nominal
- Airflow: 12.78 CFM
- Noise Level: 30.5 dB
- Bearing Type: Ball bearing
- Dimensions: 50 × 50 × 10 mm
- Weight: 21 grams
- Connector: 3-pin, 170mm lead wire
- Temperature Range: Operating (typical industrial range)
Typical Applications
- Server and network equipment cooling
- Industrial electrical enclosure ventilation
- Power supply thermal management
- Control cabinet and panel cooling
- Electronics equipment case fans
- Low-voltage DC thermal systems
Compatibility & Replacements
Compatible With
- Any 12VDC power source with 0.15A capacity or greater
- Industrial control systems and electrical enclosures
- Server cases and equipment requiring 50mm fan cutouts
- Equipment with 3-pin fan connectors and RPM monitoring capability
Replaces / Drop-In Replacement For
- Original AVC C5010T12L units in existing installations
- Other OEM 50 × 50 × 10 mm 12VDC fans with equivalent connector specifications
Works With
- PWM fan controllers for variable speed operation
- 12VDC industrial power supplies
- RPM monitoring systems and fan speed sensors
- Standard 3-pin DC fan connectors and interfaces
