Overview
The Eagle Signal HA43A6 is a Microflex timer module built for reliable, repeatable time control in industrial automation applications. Operating at 120V 60Hz with a 15A output rating, this module delivers synchronized motor-driven timing ideal for manufacturing lines, process control, and machinery sequencing. Eagle Signal, a Danaher Controls brand, has been manufacturing precision timers and counters for decades, making the HA43A6 a trusted choice for engineers maintaining legacy systems and OEM equipment.
Key Features
- Microflex modular construction for flexible configuration and easy maintenance
- 0–20 minute adjustable time range with repeatable accuracy
- Synchronous motor-driven mechanism ensures reliable, drift-free timing
- 15A rated contact output handles standard industrial loads
- 120V 60Hz operating voltage (per product designation 2C77)
- Used condition, fully tested and functional
Technical Specifications
| Voltage / Frequency | 120V AC, 60Hz |
| Output Rating | 15A @ 120V AC |
| Time Range | 0–20 minutes |
| Mechanism Type | Synchronous motor-driven with clutch |
| Housing | Microflex modular |
| Model Series | Eagle Signal / Danaher Controls |
| Mounting | Panel or DIN rail (verify with installation manual) |
| Reset Time | Typical < 200ms (synchronous reset) |
| Input Burden | Motor & clutch draw per Danaher specifications |
| Repeatability | ±3/4% of full scale (standard Eagle Signal) |
Typical Applications
- Manufacturing equipment timing and sequencing
- Pump and motor control delay circuits
- Conveyor system process timing
- Pneumatic and hydraulic system activation
- Batch process and cycle control
- Industrial maintenance replacement for legacy Eagle Signal timers
Compatibility & Replacements
Compatible With
- Industrial PLC and relay logic control circuits
- 120V AC single-phase power systems
- Panel-mounted or DIN-rail automation cabinets
- Danaher Controls timer ecosystems (Veeder-Root, Dynapar brands)
- Standard industrial automation wiring and terminal blocks
Replaces / Drop-In Replacement For
The Eagle Signal HA43A6 is a replacement for other Eagle Signal Microflex timer modules with matching 120V 60Hz, 15A, 0–20min specifications. Verify compatibility with your system integrator before ordering to ensure mounting, terminal configuration, and control circuit logic match your application. Consult the original equipment documentation or contact Danaher Controls directly for specific model cross-references.
Works With
- Legacy industrial control systems using electric timers
- Electromechanical relay logic circuits
- 24V and 120V AC control signal inputs
- Standard 15A output load circuits
- Installation in equipment from major automation manufacturers (Allen-Bradley, Siemens, GE, etc.)
