Overview
The Gordos LR38595 E46203 relay module (0AC5 series) is a proven industrial relay I/O module designed for switching and control applications in manufacturing and processing equipment. This listing includes a lot of 2 units. Originally manufactured by Gordos Arkansas for web offset printing, textile machinery, and similar industrial applications, these modules provide reliable DC logic input switching with robust AC output switching capacity.
Key Features
- 3A DC input rating with 3–8 VDC operating range
- 280 VAC output switching capacity at 60 Hz
- Compact DIP-style package for easy integration into existing control panels
- 0AC5 series designation for rapid identification and cross-reference
- Lot of 2 units — economical replacement or spare stock for multiple machines
Technical Specifications
- Input Voltage: 3–8 VDC
- Input Current: 3 A
- Output Voltage: 280 VAC
- Frequency: 60 Hz
- Series: 0AC5
- Manufacturer: Gordos Arkansas
- Package Style: DIP module
- Dimensions: Approx. 4.5 × 4 × 1.5 cm
- Weight: ~0.1 kg per unit
- Quantity in Lot: 2 units
- Condition: Used, tested, fully functional
Typical Applications
These relay modules are commonly found in:
- Web offset printing machinery and press controllers
- Textile looms and dyeing equipment
- Industrial splicers and feed mechanisms
- Process control and automation cabinets requiring DC logic input to AC load switching
- Machine retrofit and spare parts inventory for legacy equipment
Compatibility & Replacements
Compatible With
- Industrial relay control cabinets using 280 VAC output loads
- Control systems with 3–8 VDC logic or sensor inputs
- DIP-mount relay sockets and standard PCB relay footprints
- 60 Hz power distribution systems (North American standard)
Replaces / Drop-In Replacement For
Verify compatibility with your original equipment documentation. The following part numbers are associated with this module:
- Gordos 069320681 (manufacturer internal reference)
- OEM reference OAC5A-12 (some Butler splicer applications)
Always cross-check your original part number and electrical specifications before ordering replacement or spare units.
Works With
- Butler splicer systems (documented application)
- DIN-rail mounted control enclosures
- Standard relay mounting sockets and PCB headers
- Legacy industrial control systems and PLC cabinets using 3–8 VDC command signals
