<h2>Overview</h2>
<p>The <strong>General Electric U035F2</strong> is a single-phase, fused pull-out AC disconnect switch rated for 30A at 120/240VAC. Manufactured by Midwest Electric Products under the GE/Midwest Duck brand, this switch is purpose-built for air conditioning and heat pump disconnection at the service entrance or load side. Its 3 horsepower (3 hp) power rating and 10 kA short-circuit interrupt capacity make it suitable for residential and light commercial HVAC applications.</p>
<h2>Key Features</h2>
<ul>
<li><strong>Fusible Design:</strong> Fused pull-out cartridge system for circuit protection.</li>
<li><strong>Removable Pullers:</strong> Pullers are removable or reinstallable in the OFF position for safe maintenance access without full disconnect.</li>
<li><strong>Galvanized Steel Enclosure:</strong> Zinc-coated, powder-coated metallic housing for corrosion resistance and durability in outdoor environments.</li>
<li><strong>NEMA 3R Rating:</strong> Rated for use as a service entrance disconnect with IP54-equivalent protection against rain and dust.</li>
<li><strong>Straight-In/Straight-Out Wiring:</strong> Simplified terminal design reduces installation time.</li>
</ul>
<h2>Technical Specifications</h2>
<ul>
<li><strong>Voltage Rating:</strong> 120/240VAC, single-phase</li>
<li><strong>Current Rating:</strong> 30 Amps</li>
<li><strong>Power Rating:</strong> 3 HP</li>
<li><strong>Type:</strong> Fusible (fused pull-out)</li>
<li><strong>Switch Configuration:</strong> DPST (double-pole single-throw), 2 poles</li>
<li><strong>Short Circuit Interrupt Rating:</strong> 10 kA</li>
<li><strong>Enclosure Material:</strong> Galvanized/powder-coated steel</li>
<li><strong>Enclosure Rating:</strong> NEMA 3R</li>
<li><strong>Mounting:</strong> Surface-mounted, top open door</li>
<li><strong>Conductor Size:</strong> Solid copper/aluminum 14–8 AWG; stranded copper/aluminum 14–3 AWG (line/load)</li>
<li><strong>Dimensions:</strong> 7 in (H) × 5 in (W) × 2-1/8 in (D)</li>
<li><strong>Certifications:</strong> UL/CUL listed</li>
</ul>
<h2>Typical Applications</h2>
<p>The U035F2 is commonly deployed in the following scenarios:</p>
<ul>
<li>Central air conditioning and heat pump service disconnects</li>
<li>HVAC equipment branch circuit protection</li>
<li>Residential and light commercial air conditioner disconnect at meter or load panel</li>
<li>Outdoor/exposed location installations (NEMA 3R weatherproof rating)</li>
</ul>
<h2>Compatibility & Replacements</h2>
<h3>Compatible With</h3>
<ul>
<li>Standard residential and light commercial electrical distribution panels</li>
<li>Single-phase AC equipment rated 30A at 240V or less</li>
<li>Fused circuit protection schemes</li>
<li>Outdoor/NEMA 3R-rated enclosure systems</li>
</ul>
<h3>Replaces / Drop-In Replacement For</h3>
<p>Verify compatibility with your system integrator before ordering. Disconnect switch replacements may require specific voltage, amperage, and mounting specifications unique to your installation.</p>
<h3>Works With</h3>
<ul>
<li>Fused cartridge systems (standard 30A fuse blocks)</li>
<li>Single-phase service entrance configurations</li>
<li>Standard electrical code-compliant HVAC disconnect applications (NEC Article 440)</li>
</ul>
