Overview
The General Electric 5K32EG284 is a three-phase AC induction motor designed for industrial general-purpose duty. Delivering 1/4 horsepower at 1725 RPM, this motor operates on 208-230V or 460V three-phase power, making it suitable for equipment requiring continuous, reliable torque in manufacturing, HVAC, pump, and conveyor applications. Frame 48 construction ensures compact footprint while maintaining NEMA design compliance.
Key Features
- Three-phase induction motor design for efficient, low-maintenance operation
- 1/4 HP power output at 1725 RPM base speed
- Multiple voltage support: 208-230V and 460V three-phase
- Frame 48 NEMA-compliant casting for secure mounting and thermal control
- Thermal overload protection for extended component life
- Cast iron construction for durability in industrial environments
Technical Specifications
- Horsepower: 1/4 HP
- Speed (Base): 1725 RPM
- Voltage: 208-230V / 460V three-phase, 60 Hz
- Phase: 3-phase AC
- Frame Size: 48
- Current (Approximate): 1.5A at 208V, full load
- Enclosure Type: Open Drip Proof (ODP) or Totally Enclosed Fan Cooled (TEFC)
- Insulation Class: F or higher
- Duty Rating: Continuous
- Thermal Protection: Integral thermal overload relay
Typical Applications
- Centrifugal and positive displacement pumps
- Air compressors and pneumatic equipment
- Conveyor systems and material handling
- HVAC blower and fan motors
- Machine tool drive systems
- Industrial agitators and mixers
Compatibility & Replacements
Compatible With
- Standard NEMA frame 48 mounting pads and bolt holes
- Three-phase 208-230V and 460V electrical systems
- Soft-start and variable frequency drive (VFD) systems (standard induction design)
- Direct-online and reduced-voltage starter configurations
- Standard industrial control circuits and motor contactors
Replaces / Drop-In Replacement For
The 5K32EG284 replaces other GE 1/4 HP, 1725 RPM, frame 48 three-phase motors of equivalent voltage rating. Verify specific mounting configuration and shaft dimensions with your system integrator before ordering.
Works With
- NEMA-rated magnetic motor starters and contactors
- Thermal overload relays and protection circuits
- Standard industrial electrical enclosures and control panels
- Soft-start units and variable frequency drives (confirm VFD compatibility with drive manufacturer)
- Power distribution equipment rated for three-phase 208-230/460V service
