Overview
The GARCOR JBA3U-F3B072-8 is a precision Type J thermocouple probe engineered for industrial temperature monitoring and control applications. As a key component in process automation and PLC-based systems, this thermocouple delivers reliable, fast-response temperature measurement across a wide operating range. The robust stainless steel construction ensures durability in demanding industrial environments.
Key Features
- Type J Thermocouple: Optimized for iron-constantan junction measurement, suitable for -20 to +750°C applications
- 1/8″ Diameter Probe: Compact design for tight mounting spaces and fast thermal response
- Bayonet Mounting Style: Quick-connect design for tool-free installation and removal
- 316 Stainless Steel Sheath: Corrosion-resistant construction for harsh industrial and wet environments
- Ungrounded Junction: Isolated measurement to prevent ground loop interference
- Standard Male Plug Connection: Compatible with common industrial connector standards
- 72″ Stainless Steel Braid: Extended reach with durable, flexible protective shielding
Technical Specifications
- Thermocouple Type: Type J (Iron-Constantan)
- Probe Diameter: 1/8″ (3.2 mm)
- Sheath Material: 316 Stainless Steel
- Cable Length: 72″ (1.83 m) stainless steel braid
- Mounting Style: Bayonet (variable depth)
- Junction Type: Ungrounded
- Connector Type: Standard Male Plug
- Temperature Range: -20 to +750°C (-4 to +1382°F)
- Response Time: Fast thermal response (depends on immersion depth)
- Series/Part Family: GARCOR JBA3U-F3B072 series
Typical Applications
- PLC-based process control and monitoring systems
- Industrial oven and furnace temperature measurement
- Plastic injection molding equipment control
- Food processing and thermal processing applications
- HVAC system monitoring and optimization
- Machine tool temperature supervision
- Heat treatment and thermal cycle verification
Compatibility & Replacements
Compatible With
- PLC processors with analog thermocouple input modules
- Industrial control systems accepting Type J thermocouple signals
- Temperature data acquisition and monitoring hardware
- Motion control and automation platforms with temperature feedback loops
- Legacy and modern PLC systems with standard thermocouple input ports
Replaces / Drop-In Replacement For
- Other GARCOR JBA3U-F3B072 series variants (verify specific cable length and configuration with your integrator)
- Industrial thermocouple probes with identical Bayonet mounting and 1/8″ diameter specifications
- Standard Type J probes in existing control cabinets (confirm plug compatibility before replacement)
Works With
- Analog input modules compatible with Type J thermocouple signals
- PLC programming software (Studio 5000, TIA Portal, and others) via temperature data acquisition
- SCADA and industrial HMI platforms accepting thermocouple input
- Process control systems and distributed I/O modules
- Standard thermocouple extension cables and junction boxes
