Overview
The Eurotherm 106/HL/K/0-1000C/115V/XII is a single-loop temperature controller from Eurotherm’s industry-standard 106 series, engineered for demanding process heating applications. This compact unit combines precise PID temperature control with a wide measurement range of 0–1000°C, making it suitable for furnace control, heat treatment, and industrial oven regulation. The Type K thermocouple input accepts standard K-type sensors, while 115V AC power ensures compatibility with North American industrial electrical infrastructure.
Key Features
- Type K thermocouple input for direct sensor integration
- High Limit (HL) function provides over-temperature protection and safety shutdown capability
- 0–1000°C measurement range with adjustable setpoints
- PID control algorithm for smooth, stable temperature regulation
- Compact form factor suitable for panel and DIN-rail mounting
- 115V AC input voltage configuration for North American applications
Technical Specifications
- Product Model: Eurotherm 106/HL/K/0-1000C/115V/XII
- Temperature Input Type: Type K Thermocouple
- Measurement Range: 0–1000°C
- Control Function: High Limit (HL) with safety shutdown
- Power Supply: 115V AC, 50/60 Hz
- Control Output: Process variable output and relay/solid-state output for heating element control
- Display: LED or LCD readout (model-dependent)
- Safety Features: Over-temperature protection via High Limit function
- Thermocouple Compensation: Cold junction compensation built-in
- Communication: Verify controller variant for serial or optional Modbus support
Typical Applications
The Eurotherm 106/HL/K/0-1000C/115V/XII is commonly deployed in:
- Industrial furnace temperature regulation and monitoring
- Heat treatment and annealing processes
- Kiln and oven control systems
- Laboratory and production heating equipment
- Thermal processing lines requiring precise setpoint control
- Legacy system upgrades and replacements in North American facilities
Compatibility & Replacements
Compatible With
- Type K thermocouples and standard industrial temperature sensors
- Contactor and solid-state relay (SSR) control outputs
- Standard industrial 115V AC electrical distribution systems (North America)
- Panel and DIN-rail mounting environments
- PLC and data acquisition systems accepting 4–20 mA or relay inputs
- Legacy heating and process control system architectures
Replaces / Drop-In Replacement For
The Eurotherm 106/HL/K variant directly replaces earlier Eurotherm 106 models with identical input/output configuration and pinouts. Verify your specific unit’s thermocouple type and voltage before installation. Contact your system integrator for exact cross-reference documentation.
Works With
- Type K thermocouple sensors and compensating cables
- Eurotherm’s legacy configuration and setup documentation
- Industrial SCADA systems receiving analog or digital process feedback
- Manual temperature setpoint adjustment via front-panel dial or buttons
- Optional Eurotherm communication modules (verify model variant for support)
