Overview
The Emerson Ovation 1C31116G04 is a voltage input personality module with integrated temperature sensor for the Ovation Distributed Control System (DCS). This module is mainly used for cold junction compensation (CJC) of thermocouple signals, measuring the temperature of the terminal block through a built-in temperature sensor, and calculating the actual temperature by combining with the thermocouple voltage signal to solve measurement errors caused by temperature change of the reference end. The module functions as a key component in Ovation control systems, which are widely used in power generation and industrial automation applications.
Key Features
- 8 Analog Input Channels for voltage signal acquisition from field sensors
- Temperature Sensor integrated for cold junction compensation (CJC) on thermocouple inputs
- High Accuracy – ±0.1% of full scale accuracy with 0.01% resolution
- Industrial Operating Range – operates reliably from -40°C to +85°C
- 24 VDC Power Supply for standard industrial voltage compatibility
- Terminal Block Cover – designed to be used with terminal block cover (1C31207H01) to maintain uniform temperature in the terminal block and sensor area
Technical Specifications
- Module Type: Analog Input Personality Module
- Number of Channels: 8
- Input Signal: Voltage with temperature sensor for thermocouple CJC
- Accuracy: ±0.1% of full scale
- Resolution: 0.01% of full scale
- Power Supply: 24 VDC
- Operating Temperature: -40°C to +85°C
- Product Weight: 0.8 kg
- Manufacturer: Emerson Process Management
- System: Ovation Distributed Control System
Typical Applications
This module is used in various applications within power generation and industrial processes, such as monitoring temperature, pressure, flow rate, and other continuous variables. Common uses include:
- Thermocouple temperature measurement with automatic cold junction compensation
- Process monitoring and control in power plants and refineries
- Industrial automation systems requiring precise analog signal acquisition
- DCS-based process control loops
- Field instrument signal conditioning and measurement
Compatibility & Replacements
Compatible With
- Emerson Ovation Distributed Control System (DCS)
- Ovation system base units and I/O racks
- Terminal block cover 1C31207H01 (required for temperature sensor operation)
- Ovation application software and engineering platforms
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator or Emerson support before ordering to confirm if this module directly replaces an older unit. Model numbers can vary by platform version and configuration.
Works With
- Emerson Ovation DCS software platforms
- Ovation I/O subsystem architecture
- Industrial standard field sensors and transducers
- PLC and automation control networks supporting analog process inputs
