Edwards Adaptabeacon Light Beacon 52A-N5

Edwards Adaptabeacon Light Beacon 52A-N5

The Edwards Adaptabeacon Light Beacon 52A-N5 is a high-performance visual signaling device designed for both indoor and outdoor applications. Its robust construction and powerful illumination make it ideal for environments requiring clear and reliable visual alerts.

Key Features

• High-Intensity Illumination: Equipped with a 40-watt halogen lamp, the beacon delivers a luminous output of 3,328 candela, ensuring visibility even in high ambient noise areas.
• Durable Construction: The beacon features a cast metal base and a polycarbonate dome, providing weatherproof protection and easy maintenance.
• Flexible Mounting Options: Designed for versatility, it can be mounted vertically, facing up or down, and is suitable for 1/2-inch NPT conduit or surface mounting.
• Efficient Operation: Operating at 120 VAC with a current draw of 0.35 A, it offers a flash rate of 65 flashes per minute, effectively capturing attention.
• Extended Service Life: The halogen lamp boasts an average life of 25,000 hours, reducing the need for frequent replacements.

Specifications

• Voltage Rating: 120 VAC
• Wattage: 40 W
• Amperage Rating: 0.35 A
• Light Output: 3,328 cd
• Flash Rate: 65 fpm
• Average Lamp Life: 25,000 hours
• Operating Temperature Range: -31°F to 150°F (-35°C to 66°C)
• Mounting: 1/2-inch NPT conduit or surface mount
• Dimensions: 6-inch diameter, 8.5-inch height
• Certifications: UL 1638, cUL Listed

The Edwards Adaptabeacon Light Beacon 52A-N5 is engineered to provide maximum brilliance and long-term durability with minimal maintenance, making it an excellent choice for signaling needs in various industrial and commercial settings.
