Overview
The Ebmpapst 3414 24V DC fan is a compact, high-efficiency axial cooling fan designed for industrial and electronics cooling applications. With a 92x92x25mm footprint and low power consumption, the 3414 delivers dependable thermal management in space-constrained environments such as control cabinets, IT equipment, and inverter cooling.
Key Features
- Compact Design: 92x92x25mm form factor fits tight enclosures without sacrificing airflow performance
- 24V DC Operation: Nominal 24V DC with 18–28V operating range
- Efficient Motor: Glass-fiber reinforced plastic housing and impeller for durability
- Ball Bearing Construction: Reverse polarity and locked rotor protection included
- Wide Temperature Range: Operates from −20°C to +70°C
- Quiet Operation: Low noise output suitable for office and laboratory environments
Technical Specifications
- Voltage: 24V DC nominal; 18–28V DC operating range
- Power Consumption: ~2.4W nominal
- Current Draw: ~0.1A typical
- Speed: 2700 RPM
- Airflow: 84 m³/h (approximately 49 CFM)
- Dimensions: 92x92x25mm
- Bearing Type: Ball bearing
- Motor Protection: Reverse polarity and locked rotor protection
- Housing & Impeller Material: Glass-fiber reinforced plastic
- Airflow Direction: Exhaust over struts
Typical Applications
The Ebmpapst 3414 is widely used in:
- Electronics enclosures and server cabinets
- Industrial control cabinets and VFD cooling
- Inverter and power supply thermal management
- Compact ventilation systems requiring low-noise operation
- IT equipment and distributed processing units
Compatibility & Replacements
Compatible With
- 24V DC power supplies and industrial control systems
- Standard 92mm mounting footprint equipment
- Electronics requiring IP20 or equivalent ventilation protection
- Industrial automation and HVAC control systems
Replaces / Drop-In Replacement For
- Ebmpapst 3414N (standard 2-wire variant)
- Ebmpapst 3414N/2 (low-power variant)
- Other 92mm 24V axial fans with similar mounting
- Verify compatibility with your system integrator before ordering
Works With
- 24V DC industrial control networks
- PLC and motion controller cooling systems
- Standard 92mm fan shrouds and ducts
- Modular enclosure and cabinet ventilation designs
