Overview
The Eaton Dynamatic 15-796-1 snubber circuit board is a PCB component designed for use in Eaton Dynamatic inverter and drive systems. Snubber boards manage voltage transients and provide critical suppression and gating functions in solid-state power conversion equipment. This legacy component is commonly found in industrial motor control, AC/DC conversion, and variable frequency drive applications. The board is offered in used condition and suits maintenance, repair, and OEM applications where Eaton Dynamatic compatibility is required.
Key Features
- Snubber circuit topology for voltage transient suppression and management
- Compatible with Eaton Dynamatic inverter and drive platforms
- Legacy design for retrofit and replacement applications
- PCB-based module for direct mounting in Dynamatic equipment
- Used component in working condition, ideal for in-stock availability and immediate deployment
Technical Specifications
- Part Number: 15-796-1
- Alternate Designation: T950605
- Manufacturer: Eaton Corporation (Dynamatic Division)
- Product Type: Inverter Snubber Circuit Board (PCB)
- Condition: Used
- Application: Inverter and AC Drive Systems
- Mounting: PCB Module (direct mount in Dynamatic chassis)
- Unit Quantity: 1
Typical Applications
- AC/DC inverter retrofit and repair
- Eaton Dynamatic variable frequency drive (VFD) maintenance
- Industrial motor control systems using legacy Dynamatic platforms
- Solid-state power conversion equipment requiring snubber suppression
- OEM and aftermarket drive system rebuilds and upgrades
Compatibility & Replacements
Compatible With
- Eaton Dynamatic inverter platforms and drives
- Eaton Cutler-Hammer legacy motor control systems
- Industrial solid-state power conversion equipment using Dynamatic snubber functions
- Systems requiring PCB-based voltage transient suppression modules
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator or original equipment documentation before ordering. The 15-796-1 is a specific snubber board designed for particular Dynamatic equipment configurations. Cross-reference your equipment model and revision level to confirm this board is the correct replacement.
Works With
- Eaton Dynamatic inverter and AC drive control systems
- Equipment using solid-state suppression and gate-drive circuits
- Industrial facilities standardized on Eaton Dynamatic platforms
- Integration with other Dynamatic PCB modules and power stages
