Overview
The Eaton CSDS4A3CY2202 is a pre-assembled 3-wire sensor connection cable designed for photoelectric and proximity sensors in industrial automation applications. This Global Plus series cordset provides a straightforward, reliable interface between proximity sensors and control systems. The cable features a 4-pin micro-style female connector and is manufactured to IP67 specifications for use in demanding environments.
Key Features
- 3-Wire Configuration: Brown, Blue, and Black conductor wires for standard photoelectric sensor applications
- 4-Pin Micro-Style Connector: Female receptacle with straight-angle design for secure sensor connections
- 6.5-Foot Cable Length: 2-meter length accommodates typical sensor-to-controller distances without excessive slack
- 320 VAC / 4A Rating: Rated for industrial voltage and current requirements
- PVC Jacket: Durable polyvinyl chloride insulation rated IP67 for moisture and dust protection
- 22 AWG Wire Gauge: Appropriate conductor size for sensor-level signal transmission
Technical Specifications
- Cable Length: 6.5 ft (2 m)
- Wire Configuration: 3-Wire
- Connector Type: 4-Pin Micro-Style Female
- Connector Style: Straight Angle
- Wire Gauge: 22 AWG
- Voltage Rating: 320 VAC
- Current Rating: 4 A
- Cable Material: PVC Jacket
- IP Rating: IP67
- Conductor Colors: Brown, Blue, Black
- Series: Eaton Global Plus
Typical Applications
The CSDS4A3CY2202 cordset is suitable for:
- Photoelectric sensor connections in factory automation
- Proximity sensor integration with PLC and control modules
- Machine vision and detection system interfaces
- Industrial motion control and robotic applications
- General industrial sensor networking in harsh environments
Compatibility & Replacements
Compatible With
- Eaton Global Plus proximity sensors (3-wire DC types)
- Photoelectric sensors with 3-wire micro-style connectors
- Industrial automation controllers accepting micro-style sensor inputs
- Standard 4-pin micro female receptacle sensor headers
Replaces / Drop-In Replacement For
- CSDS4A3RY2202 (right-angle variant)
- Original OEM sensor cordsets with 4-pin micro connectors on Global Plus systems
Works With
- Eaton/Cutler-Hammer Global Plus sensor family
- Rockwell CompactLogix and ControlLogix I/O modules with sensor-level inputs
- Siemens S7-1200 / S7-1500 PLC proximity sensor inputs
- Standard micro-style 4-pin female connector receptacles
- DC sensor networks (10–30 Vdc typical for 3-wire photoelectric applications)
