Overview
The Eaton CSAS4F4CY2210 is a high-quality 4-pin sensor cable cordset engineered for industrial automation and machinery control. With a 10-meter cable length and micro-style female connector, this cable is part of Eaton’s Global Plus line, delivering essential connectivity for sensors and control devices in demanding manufacturing and processing environments.
Key Features
- 4-pin micro-style female connector for standard sensor integration
- 10-meter (32.8 ft) cable length for extended reach between control cabinet and field sensors
- PVC cable jacket provides standard protection and flexibility in compact routing applications
- 4-pole wiring configuration supports dual-function and complementary output sensors
- Single keyway connector design prevents mis-mating and ensures secure connections
- Rated for 320 VAC/VDC with 4A current capacity for standard industrial duty cycles
Technical Specifications
- Manufacturer: Eaton Cutler-Hammer
- Series: Global Plus
- Cable Length: 10 m (32.8 ft)
- Connector Type: 4-Pin Micro-Style Female
- Connector Interface: 1/2-20 UNF
- Pole Count: 4
- Voltage Rating: 320 VAC/VDC
- Current Rating: 4 A
- Cable Jacket: PVC
- Wire Configuration: Copper/Stranded
- IP Rating: IP67
- Orientation: Straight angle connector
Typical Applications
- Photoelectric sensor connections for object detection and position sensing
- Inductive proximity sensor wiring in metal detection and switching applications
- Industrial automation control circuits and machine logic integration
- Equipment-to-PLC and cabinet-to-field device interconnection
- Sensor signal transmission in packaging, material handling, and assembly machinery
Compatibility & Replacements
Compatible With
- Eaton Global Plus photoelectric and proximity sensor series
- Standard 4-pin micro M12-style sensor interfaces
- Industrial control panels and PLC input modules
- Sensor signal conditioners and relay modules accepting 4-pole micro connectors
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering to ensure this cordset matches your sensor connector type and electrical specifications.
Works With
- Eaton inductive proximity sensors (E57 series)
- Eaton photoelectric sensors (Global Plus line)
- Standard 4-pin M12 micro connector sockets
- Control systems supporting 320 VAC/VDC and 4A rated circuits
