Overview
The Eaton 8532B-6501 is a compact plug-in relay output device designed for precision electrical switching in control circuits. This 50 Series relay features SPDT (single-pole, double-throw) Form C contacts and is rated for 2A at 115V, making it suitable for general-purpose control applications in industrial and commercial environments. The device is engineered to deliver reliable, repeatable switching performance in panel-mounted systems.
Key Features
- SPDT Form C relay contacts for flexible switching configurations
- 2A rated switching capacity at 115V
- Plug-in design for easy installation in standard relay sockets
- 50 Series compatibility with Eaton control systems
- Compact form factor for space-constrained applications
- Proven reliability in industrial control environments
Technical Specifications
The following specifications define the electrical and physical characteristics of this relay output device:
Typical Applications
The Eaton 8532B-6501 is commonly deployed in:
- Industrial control panels and electrical distribution systems
- Photoelectric sensor output signal conditioning
- Low-frequency, general-purpose control power switching
- Commercial HVAC and lighting control circuits
- Automation systems requiring reliable relay switching
Compatibility & Replacements
Compatible With
- Eaton Cutler-Hammer 50 Series relay sockets
- Standard 8-pin or 11-pin relay footprints
- Control systems requiring Form C SPDT contacts
- Sensor output device mounting in industrial panels
Replaces / Drop-In Replacement For
For specific cross-reference information regarding equivalent models or direct replacements, verify compatibility with your system integrator or consult Eaton’s product selection guide before ordering.
Works With
- Eaton photoelectric sensors (50 Series)
- Eaton control devices requiring relay output modules
- Standard industrial relay socket assemblies
- Low-voltage DC and AC control circuits
