Overview
The Eagle Signal HM33A6444 is a synchronous motor-driven electric reset timer engineered for precise time delay control in industrial automation. This surface-mount timer operates on 120VAC/60Hz power and provides a 30-second adjustable time range, making it suitable for a wide range of cycle timing and sequencing applications. The unit is part of Eagle Signal’s established timer product family, known for reliable performance in manufacturing and process automation environments.
Key Features
- Electric reset timer with synchronous motor-driven mechanism
- 120VAC/60Hz coil voltage operation
- 30-second adjustable time range
- Surface-mount design for panel or enclosure installation
- Heavy-duty industrial construction for demanding applications
- Reliable electromechanical design with minimal maintenance
Technical Specifications
- Model Number: HM33A6444
- Coil Voltage: 120VAC
- Frequency: 60 Hz
- Time Range: 0-30 seconds
- Mounting Type: Surface mount
- Timer Type: Electric reset timer
- Manufacturer: Eagle Signal (Danaher Controls)
- Circuit Configuration: CYCL-FLEX compatible
Typical Applications
- Industrial process sequencing and cycle control
- Machine start/stop delay timing
- Conveyor and transfer line operation
- Pump and motor soft-start applications
- Production line synchronization
- Maintenance and OEM equipment retrofit
Compatibility & Replacements
Compatible With
- Industrial control panels requiring 120VAC timer modules
- Systems using CYCL-FLEX timer architecture
- Danaher Controls automation systems
- Legacy and modern manufacturing equipment
Replaces / Drop-In Replacement For
- Other HM-series Eagle Signal 30-second timers with identical voltage and frequency ratings
- Verify compatibility with your system integrator before ordering
Works With
- Standard 120VAC industrial control circuits
- Relay logic and PLC-based automation systems
- General-purpose industrial automation platforms
- Mechanical and electrical control system architectures
