Overview
The Eaton E65-SMPRS9109 photoelectric sensor cable is part of Eaton’s E65 SM series, designed for reliable object detection in manufacturing, packaging, and material handling environments. This polarized reflex sensor uses a light beam and built-in mirror reflector to detect objects at distances up to 3 meters. With a pre-installed cable and straightforward wiring, the E65-SMPRS9109 offers drop-in compatibility with standard PLC and controller inputs.
Key Features
- Polarized reflex detection mode with integrated 3M sensing range
- 10-30 VDC input voltage range for DC-powered automation systems
- NPN open collector output with 100 mA maximum current rating
- Pre-assembled cable connector for quick installation
- Compact form factor suitable for tight mounting spaces
- Forward-viewing design with consistent target detection
Technical Specifications
- Manufacturer: Eaton (Cutler-Hammer)
- Model: E65-SMPRS9109
- Sensing Method: Polarized Retroreflective
- Sensing Range: 3 meters (9.8 feet)
- Input Voltage: 10-30 VDC
- Output Type: NPN Open Collector
- Maximum Output Current: 100 mA at 30 VDC
- Cable Length: Factory-installed cordset
- Connector: Polarized connector (as specified)
- Operating Temperature: Industrial standard range
Typical Applications
- Packaging and labeling machines
- Conveyor systems and material tracking
- Industrial automation and process control
- Motion control and positioning systems
- Inventory and warehouse automation
- Production line object detection
Compatibility & Replacements
Compatible With
- Allen-Bradley CompactLogix and ControlLogix PLC systems
- Siemens S7-1200 and S7-1500 controllers
- Mitsubishi FX and iQ-R series PLCs
- Omron CP1E and NJ-series controllers
- Standard 24 VDC industrial control circuits
- Industrial automation networks using discrete DC inputs
Replaces / Drop-In Replacement For
Verify with your system integrator for exact model compatibility before ordering, as the E65-SMPRS9109 is a legacy or specialty model number. Similar current-generation alternatives include E65-SMPR3 series sensors from Eaton.
