Overview
The E195601-02 PLTC cable is a multi-conductor power-limited instrumentation cable rated for 300V operation. This 20 AWG, 3-conductor cable features a bright yellow jacket that provides easy identification in complex wiring harnesses. The E195601-02 is specifically designed for industrial control circuits, instrumentation applications, and power-limited tray installations where sunlight resistance and flame retardancy are required.
Key Features
- 300V voltage rating suitable for low-voltage control and signal transmission
- 20 AWG copper conductors with Class B stranding for flexibility and reliability
- 3-conductor configuration for balanced instrumentation applications
- Yellow PVC jacket for easy cable identification and UV resistance
- UL PLTC/ITC approved for use in cable trays and industrial environments
- Flame retardant construction meets fire safety requirements
Technical Specifications
- Voltage Rating: 300V
- Conductor Gauge: 20 AWG
- Number of Conductors: 3
- Conductor Material: Bare copper, Class B stranded
- Insulation: PVC
- Jacket Color: Yellow
- Temperature Rating: 105°C maximum
- Approval Standards: UL PLTC, ITC, NEC Article 725
Typical Applications
- Industrial process control circuits and sensors
- Power-limited alarm and instrumentation wiring
- Factory automation equipment interconnections
- Tray cable installations in manufacturing facilities
- Signal transmission in control panels and junction boxes
- Petrochemical and hazardous location intrinsically safe wiring
Compatibility & Replacements
Compatible With
- Industrial control systems and PLCs
- Process instrumentation and data acquisition systems
- Cable tray, conduit, and raceway installations
- Manual and automatic control circuits
Replaces / Drop-In Replacement For
The E195601-02 part number designation indicates this is an original or compatible instrumentation cable. Verify compatibility with your system integrator before ordering, as substitute cables must match conductor gauge (20 AWG), conductor count (3), voltage rating (300V), and PLTC/ITC approvals.
Works With
- UL-listed control equipment and terminals
- Instrumentation signal interface cards
- Standard industrial connector systems (DIN, terminal blocks, crimp connectors)
- Fire-rated cable trays and support systems
