Overview
The Dodge Tigear-2 23TIEROD Size 23 Tie Rod Assembly is a critical mounting component for Dodge Tigear-2 industrial worm gearbox reducers. This assembly enables secure mechanical alignment and support for Size 23 reducer installations in high-torque industrial applications. The Dodge Tigear-2 line is engineered for demanding environments and the 23TIEROD tie rod assembly provides the structural support and adjustment capability required for optimal reducer performance and longevity.
Key Features
- Precision-engineered tie rod assembly for Dodge Tigear-2 Size 23 reducers
- Includes threaded rod ends, turnbuckle, fulcrum pin, and fastening hardware
- Enables fine alignment adjustment during installation and commissioning
- Constructed from durable materials rated for industrial use
- Complies with Dodge engineering standards and specifications
- New in Box condition with full manufacturer documentation
Technical Specifications
- Manufacturer: Dodge Industrial (Baldor/ABB)
- Part Number: 23TIEROD
- Product Category: Gearbox Mounting Hardware
- Reducer Series: Tigear-2
- Size Designation: 23
- Assembly Type: Tie Rod Kit
- Condition: New in Box
- Components Include: Threaded rod ends (qty. 2), turnbuckle (qty. 1), fulcrum (qty. 1), jam nuts (qty. 2), hex head cap screws (qty. 4)
- Application: Industrial speed reducers and power transmission systems
Typical Applications
- Motor-to-reducer mounting brackets on Tigear-2 Size 23 installations
- Mechanical alignment and vibration isolation in industrial drive systems
- Food processing, packaging, and material handling equipment
- Conveyor systems and rotary machinery requiring precise shaft alignment
- Heavy-duty industrial gearbox mounting and service installations
Compatibility & Replacements
Compatible With
- Dodge Tigear-2 Size 23 worm gearbox reducers
- Industrial motor-to-reducer coupling applications
- Standard gearbox mounting bracket systems
- Reduction equipment in food-grade (FoodSafe™) and washdown (E-Z Kleen®) configurations
Replaces / Drop-In Replacement For
- OEM Dodge 23TIEROD assemblies
- Tigear-2 Size 23 original mounting tie rod components
- Legacy Tigear (Gen 1) Size 23 compatible mounting hardware (verify with integrator)
Works With
- Dodge Tigear-2 reducers featuring standard input and output configurations
- Motor adapters and C-Face mounting arrangements
- Industrial electric motors and power transmission input sources
- Hollow-bore and solid-shaft output reducer configurations
