Overview
The Dodge DBSC-10-23 (part number 025632) is a D-series spring-set electric motor brake designed for industrial power transmission and machine control applications. Rated for 208-230/460 VAC three-phase operation, this brake provides reliable holding torque in motoring and fail-safe braking on loss of power. The “Less Hub” configuration ships without a shaft hub, allowing you to select the appropriate hub bore for your drive shaft diameter during installation.
Key Features
- Spring-set, electrically released design for fail-safe operation
- 10 lb-ft holding torque across rated voltage range
- 208-230/460 VAC three-phase, 50/60 Hz compatible
- Low current draw (approximately 0.14 amps) reduces control wiring requirements
- D-series frame design for compatibility with standard motor mounting
- Less Hub configuration for custom shaft coupling
Technical Specifications
The Dodge DBSC-10-23 meets industrial MRO standards for mechanical power transmission and automation control. Operating parameters and electrical characteristics ensure predictable engagement and release cycles in repetitive duty cycles.
Typical Applications
- Conveyor system load holding and braking
- Hoist and lift equipment safety brake
- Machine tool spindle brake
- Positive load holding on inclined drives
- Industrial automation fail-safe brake control
Compatibility & Replacements
Compatible With
- Standard D-series motor brake flange mounts
- 208-230/460 VAC three-phase industrial power systems
- 50/60 Hz AC supply
- Mechanical power transmission and automation control systems
Replaces / Drop-In Replacement For
- Dodge DBSC-10 configurations requiring 10 lb-ft torque rating
- Original equipment manufacturer brake assemblies with matching voltage/torque specifications
Works With
- AC contactor and relay control circuits
- Industrial motor starters and soft-start controllers
- Standard shaft hubs and couplings (5/8″ bore and larger)
- Mechanical load-holding applications up to rated torque capacity
