Overview
The Dodge 117160 taper-lock bushing is a precision-engineered power transmission component built for dependable performance in industrial mechanical drive applications. This stock bore Type 1610 bushing combines secure tapered engagement with a compact, flangeless profile ideal for space-constrained mounting scenarios. Manufactured using sintered steel construction, the unit delivers stable bore sizing and reliable shaft locking without protruding elements.
Key Features
- Flangeless Design: Flangeless for clean, compact application
- Secure Locking: Engineered with an 8 deg taper and a flush-mounted design with no protruding parts providing secure locking and elimination of wobble
- Sintered Steel Material: Durable construction for long service life
- Stock Bore Type: Precision-machined 1-3/16″ bore ready for immediate use
- No-Puller Removal: Jackscrew-assisted extraction without requiring external pullers
Technical Specifications
- Bore Diameter: 1-3/16 in Bore Dia
- Outside Diameter (OD): 2-1/4 in Outside Dia
- Hub Diameter: 3-1/4 in Hub Dia
- Overall Length (OAL): 1 in OAL
- Taper Angle: 8 deg Taper
- Bolt Circle: 2.13 in Bolt Circle
- Fastening Holes: 2 Bolt Holes
- Set Screw Size: 3/8 x 5/8 in Screw
- Torque Capacity: 4300 in-lb Torque
- Keyway Dimensions: 1/4 x 1/8 in Keyway
- Material: Sintered Steel
- Weight: Approximately 2.0 lb
Typical Applications
The Dodge 117160 bushing serves effectively in mechanical power transmission systems where bore reduction, alignment correction, or shaft coupling is required. Common applications include conveyor drive systems, industrial machinery, motor-to-load couplings, and pump drive assemblies. The flangeless design makes it particularly suitable for applications where installation space is limited or where clean, aesthetically integrated mounting is preferred.
Compatibility & Replacements
Compatible With
- Dodge taper-lock hub assemblies (all compatible bore sizes)
- Standard industrial electric motors and gearboxes with compatible shaft sizes
- Mechanical power transmission systems using 8-degree taper engagement
- OEM equipment designed for Type 1610 stock bore bushings
Replaces / Drop-In Replacement For
The Dodge 117160 is a direct replacement for any existing Type 1610 X 1-3/16″ KW taper-lock bushing application. Verify application compatibility with your system integrator to ensure proper fit and performance in your specific installation.
Works With
- Dodge taper-lock hubs and adapters
- Baldor mechanical drive products (Dodge is a Baldor division)
- Standard 1/4″ × 1/8″ keyway shafts
- Industrial belt drive and shaft coupling systems
