Overview
The Destaco 602 toggle clamp is a versatile, compact through-hole mounted straight line action clamp engineered for manual push/pull applications. Featuring a round plunger that moves along the clamp axis and locks securely in both extended and retracted positions, the Destaco 602 delivers reliable hold-down force in confined workspaces across automotive, aerospace, packaging, and general assembly operations.
Key Features
- Straight line action design with round plunger for push/pull clamping
- Through-hole mounting with flanged base for stable fixture installation
- Locks securely in both extended and retracted positions
- 1/4-20 threaded plunger for flexible mounting options
- Steel body construction for durability under frequent use
- Rotatable red ergonomic handle for easy access in tight setups
- Compact footprint suitable for assembly line and fixture work
Technical Specifications
- Maximum Holding Capacity: 200 lbf (900 N)
- Plunger Travel: 0.750 in (19.1 mm)
- Plunger Height: 0.410 in (10.4 mm)
- Body Thread Size: 5/8-18
- Body Width: 1.03 in
- Distance from Surface to Plunger: 0.88 in
- Distance from Front Body to End Plunger: 1.31 in
- Handle: Rotatable red design
- Material: Steel body
- Mechanical Advantage (Ef:Af): 31:1 / 28:1 (pushing/pulling)
Typical Applications
The Destaco 602 is widely used in:
- Assembly and sub-assembly operations in automotive and aerospace manufacturing
- Welding fixtures and temporary part locating
- Tensioning applications requiring controlled pressure
- Fixture checking and inspection work
- Packaging and light industrial clamping tasks
Compatibility & Replacements
Compatible With
- CNC machining centers with through-hole mounting capability
- Standard fixture plates and mounting surfaces
- Assembly workbenches and work-holding solutions
- Industrial clamp systems requiring 1/4-20 threaded interfaces
Replaces / Drop-In Replacement For
The Destaco 602 is the base model in the Destaco 602 Series. Variant models include the 602-R (with Toggle Lock Plus) and 602-MM / 602-MMR (metric versions). For specific replacement compatibility with other toggle clamp brands or legacy model numbers, verify with your system integrator before ordering.
Works With
- Manual fixture assembly and work-holding setups
- Standard industrial mounting hardware (bolts, studs, threaded holes)
- Pneumatic and manual fixture control systems
- Multi-clamp fixture arrays for gang clamping
