Overview
The Dayton BZX 20 1980 is a ball lock shank punch engineered for metal stamping and progressive die applications. This Dayton BZX 20 1980 punch features a ball lock design that provides quick-change capability and secure mounting in standard die sets. The P20.50 designation indicates round punch geometry with precision point specifications, making it suitable for high-volume production environments requiring repeatability and durability.
Key Features
- Ball Lock Design: Enables quick tool changes and consistent positioning in die assemblies
- Precision Point: P20.50 specification ensures accurate hole punching with minimal burr
- Versatile Shank Compatibility: Designed to work with standard Dayton die button cavities and punch retainer systems
- Heavy-Duty Construction: Built for continuous production use with minimal downtime
- Manufacturing-Grade Quality: Meets industry standards for precision metal stamping tooling
Technical Specifications
The following specifications are typical for this model. Verify with your die design or system integrator for exact dimensions:
- Punch Type: Ball Lock Point Larger than Shank (BZX)
- Shank Diameter Code: 20
- Point Specification: P20.50
- Overall Length: Per specification code 1980
- Design Standard: Jektole point larger than shank configuration
Typical Applications
The Dayton BZX 20 1980 punch is commonly used in:
- Progressive die stamping for automotive components
- Precision hole punching in sheet metal fabrication
- High-volume production runs requiring tool consistency
- Multi-station die sets with quick-change punch requirements
- Metal stamping operations demanding clean, repeatable holes
Compatibility & Replacements
Compatible With
- Dayton Progress ball lock punch retainer systems
- Standard Dayton die button cavities
- Progressive and compound die sets configured for ball lock punches
- Custom die assemblies designed for BZX punch geometry
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator or tooling engineer before ordering. Dayton BZX punch specifications are application-specific; direct replacement depends on exact die cavity dimensions and retainer configuration.
Works With
- Dayton Progress die components and retainers
- Standard punch press and stamping equipment
- Ball lock quick-change punch systems
- Progressive die and compound die assemblies
