Overview
The Danaher 1160-0617-065 M-3800 Rev D temperature control board is a field-proven industrial process controller from Danaher’s Partlow division. Designed for 1/16 DIN panel mounting, this unit provides precision temperature and process control in manufacturing, HVAC, and thermal processing applications. The M-3800 Rev D architecture delivers stable PID control with digital front-panel interface for setpoint and parameter adjustment.
Key Features
- Compact 1/16 DIN form factor for space-constrained panel installations
- PID control algorithm for stable temperature regulation
- Thermocouple and RTD sensor input compatibility
- Digital display and keypad interface for easy configuration
- Relay output for direct load switching or SSR drive capability
- Used, fully functional unit—in-stock and ready to ship
Technical Specifications
- Part Number: 1160-0617-065
- Model: M-3800 Rev D
- Manufacturer: Danaher Controls (Partlow Division)
- Form Factor: 1/16 DIN Panel Mount
- Control Method: PID Temperature Control
- Input Types: Thermocouple, RTD, Thermistor compatible
- Display: Digital LED/LCD Front Panel
- Output: Relay contact rated for SSR or direct load switching
- Supply Voltage: 90-264 VAC, 50/60 Hz (typical for 1160 series)
- Mounting: DIN Rail or panel-mount adapter
- Operating Temperature: 0–50°C ambient
- Unit Condition: Used, tested, fully functional
Typical Applications
- Industrial oven and furnace temperature control
- Injection molding process temperature regulation
- Heat treating and annealing operations
- HVAC zone control and boiler management
- Packaging machinery thermal control
- Food processing and cooking equipment temperature management
Compatibility & Replacements
Compatible With
- Danaher Partlow 1160 series ecosystem
- Standard DIN 43700 thermocouple and RTD inputs
- SSR (solid-state relay) and electromechanical relay loads
- Panel-mount industrial control cabinets
- Legacy temperature control system upgrades
Replaces / Drop-In Replacement For
- Partlow 1160 series M-3800 variants
- Earlier revisions (Rev A, B, C) of Danaher 1160-0617 series
- Other Danaher temperature controller modules with equivalent DIN form factor and I/O configuration
Works With
- Standard industrial thermocouple probes (J, K, T, E types)
- 100-ohm platinum RTD sensors
- 24 VDC and 120/240 VAC industrial automation networks
- Manual tuning (PID parameters configurable via front keypad)
