<h2>Overview</h2>
<p>The <strong>Eaton Cutler-Hammer CE15DNS3</strong> is a Freedom Series XT IEC contactor designed for general purpose motor control applications. This three-pole, non-reversing contactor features an 18A continuous rating and Frame D (55 mm) construction, making it suitable for motors up to 1 hp at 50-60 Hz. The open-type design with side-mounted 1 N.O. auxiliary contact provides flexible integration into motor starter circuits and control panels.</p>
<h2>Key Features</h2>
<ul>
<li>18A continuous contact current rating</li>
<li>Three-pole non-reversing configuration</li>
<li>Freedom Series XT IEC design for industrial reliability</li>
<li>1 N.O. (normally open) side-mounted auxiliary contact</li>
<li>Frame D (55 mm) compact footprint suitable for DIN rail or panel mounting</li>
<li>50-60 Hz operation at rated coil voltage</li>
<li>Open-type construction for integration into larger assemblies</li>
</ul>
<h2>Technical Specifications</h2>
<ul>
<li>Contact Current Rating: 18A continuous (AC3)</li>
<li>Poles: 3 pole, non-reversing</li>
<li>Auxiliary Contacts: 1 N.O. (side-mounted)</li>
<li>Frame Size: D (55 mm width)</li>
<li>Coil Voltage: 110-120 Vac, 50-60 Hz</li>
<li>Rated Horsepower: 5 hp @ 200-230V, 10 hp @ 460V, 15 hp @ 575V</li>
<li>Operating Frequency: 50-60 Hz</li>
<li>Type: IEC XT Open Contactor</li>
<li>Series: Eaton Freedom</li>
<li>Mounting: DIN rail or panel mountable</li>
<li>Certifications: IEC Rated, UL Listed, CSA Certified</li>
</ul>
<h2>Typical Applications</h2>
<ul>
<li>General purpose AC motor control and switching</li>
<li>Motor starter circuits for pumps, fans, and compressors</li>
<li>Industrial automation and HVAC equipment control</li>
<li>Power distribution and load management in control panels</li>
<li>Building automation and facility management systems</li>
<li>OEM equipment and machinery starter integration</li>
</ul>
<h2>Compatibility & Replacements</h2>
<h3>Compatible With</h3>
<ul>
<li>IEC 60947-4-1 compliant motor control circuits</li>
<li>DIN rail and panel-mount electrical enclosures</li>
<li>Standard 120V AC industrial control wiring</li>
<li>Eaton Freedom Series overload relays and accessories</li>
<li>Motor protection and thermal overload devices</li>
</ul>
<h3>Replaces / Drop-In Replacement For</h3>
<ul>
<li>CE15DNS3AB (same electrical specifications, same mounting)</li>
<li>Earlier Cutler-Hammer Size D open contactors with equivalent 18A, 1 N.O. configuration</li>
<li>Verify compatibility with your system integrator before ordering</li>
</ul>
<h3>Works With</h3>
<ul>
<li>IEC 60947-4-1 standardized motor control systems</li>
<li>Eaton Freedom Series starters, relays, and accessories</li>
<li>Standard 50-60 Hz three-phase motor loads</li>
<li>Thermal and electronic overload relays for motor protection</li>
<li>Emergency stop circuits and safety interlocking systems</li>
</ul>
