Overview
The Crosby 1010097 G-450 Red-U-Bolt wire rope clip is an industry-standard drop-forged steel fastener designed for reliable wire rope termination in lifting, rigging, and heavy-duty applications. The 3/8-inch G-450 Red-U-Bolt Drop Forged Wire Rope Clip is designed for securing wire rope ends in lifting and rigging applications, with drop-forged steel construction and a durable galvanized finish. The Crosby G-450 is one of the best-known wire rope clips in the industry. This clip includes nuts (2), saddle, and U-bolt and meets or exceeds all requirements of ASME B30.26 and Federal Specification Number FF-C-450E.
Key Features
- Drop-forged steel construction with galvanized finish provides 80% efficiency and excellent corrosion resistance
- The red, rounded U-bolt with thread diameter of .44″ fits over the rope, with saddle and .75″ nuts to tighten the U-bolt, clamping the rope—easy to install with no specialized tools or swagging equipment needed
- Each base has a Product Identification Code (PIC) for material traceability, the name CROSBY or CG, and its size forged into it
- The entire clip is galvanized to resist corrosive and rusting action
- Allows efficient creation of loop termination or joining two or more wire ropes together without need for swagging or socketing, making it crucial rigging hardware that’s easily installed, removed, or adjusted
Technical Specifications
- Model: G-450, Brand Part No.: 1010097
- Clip Type: U-Bolt, Wire Rope Diameter: 3/8 in
- U-Bolt Diameter: 0.44″
- Saddle Width: 1.50″
- Nut Size: 0.75″
- Efficiency Rating: 80% based on catalog breaking strength of wire rope for 1/8″ – 7/8″ sizes
- Meets or exceeds all requirements of ASME B30.26 and Federal Specification FF-C-450 TYPE 1 CLASS 1
- Material: Drop-Forged Steel
- Finish: Galvanized
- Minimum Torque: 45 ft-lbs
- Package Quantity: 100 per box
- Weight per 100: 48 lbs
Typical Applications
This clip is widely used in winch lines, guy lines, and sling assemblies to create loop terminations, and is perfect for temporary rigging where permanent fittings are impractical, allowing quick and reusable connections for wire ropes. It is ideal for industrial rigging, marine applications, construction sites, and any scenario requiring quick, tool-free wire rope termination or joining.
Compatibility & Replacements
Compatible With
- 3/8-inch diameter wire rope (9–10 mm)
- Standard rigging and lifting equipment
- Winch systems and guy-line assemblies
- Load-rated slings and cable assemblies
Replaces / Drop-In Replacement For
This part number is the direct OEM Crosby designation. This model is available under part numbers 1010051, 1010131, 1010097, and 1010079 for different cable sizes. The 1010097 is the exclusive part number for the 3/8-inch G-450 Red-U-Bolt clip. Compatible alternative wire rope clips from other manufacturers should be verified for load rating and standards compliance before substitution.
Works With
- ASME B30.26–certified rigging systems
- Federal Specification FF-C-450 compliant equipment
- Standard lifting and rigging hardware
- All industrial wire rope diameters matching 3/8 inch specification
