Overview
The Convectronics 006-10062 is a compact, solid-state power control module engineered for industrial automation and resistive load applications. It offers infinitely variable phase control with exceptional stability and transient suppression, making it ideal for precise power management in heating systems, thermal process control, and motion applications requiring accurate voltage regulation.
Key Features
- Infinitely variable phase control for resistive loads up to 25A maximum
- Solid-state circuitry with modified transient suppression and exceptional stability
- Adjustable output voltage from 17% to 99% of applied input voltage
- External potentiometer with dial plate and knob for intuitive output control
- Trimming potentiometer for turn-on voltage adjustment
- Integrated heat sink recommended for loads exceeding 15A
- Single-phase 60 Hz operation
Technical Specifications
- Input Voltage: 110–277V, single phase, 60 Hz
- Output Voltage: Adjustable 17%–99% of applied input
- Maximum Current Rating: 25A (see ambient temperature derating curve)
- Maximum Power Consumption: 50 watts
- Maximum Operating Temperature: 75°C (measured at base plate center)
- Circuit Protection: Install with circuit fused at 120% rated load (30A maximum)
- Control Interface: External potentiometer/switch with included dial plate and knob
- Heat Sink: Recommended for loads exceeding 15A
Typical Applications
The Convectronics 006-10062 is widely used in industrial heating, air heater control, thermal process management, and motion control systems where proportional voltage regulation is required. Its solid-state design and compact form factor make it suitable for panel mounting in control cabinets, retrofit installations, and OEM equipment.
Compatibility & Replacements
Compatible With
- Industrial resistive load control systems (heaters, ovens, thermal elements)
- Single-phase 60 Hz power distribution (110V, 120V, 208V, 240V, 277V circuits)
- Industrial automation and process control equipment
- Thermal management and air heater applications
- Control panel and cabinet-mounted installations
Replaces / Drop-In Replacement For
The Convectronics 006-10062 is the original part number; verify model equivalency with your system integrator for legacy equipment. Ensure input voltage and load current ratings match your application before ordering.
Works With
- Convectronics heating equipment and air heater systems
- Standard single-phase 60 Hz industrial power supplies
- External potentiometer and switch control interfaces
- Industrial thermal and heating process control systems
