Overview
The Centralab PA-6013 is a military-grade rotary selector switch delivering dependable multi-pole switching for demanding industrial and military applications. This Centralab PA-6013 model provides 4 independent poles with 5 selectable positions, enabling flexible circuit control with a single rotary action. Built with time-proven ceramic insulation and solder-lug termination, the PA-6013 meets the exacting reliability standards required in control panels, instrumentation, and legacy electronic systems.
Key Features
- 4-Pole, 5-Position Configuration: Allows simultaneous switching of up to four independent circuits at each rotation position
- Military-Grade Construction: Designed to withstand demanding operational and environmental conditions typical of military equipment
- Ceramic Insulation: Steatite ceramic wafer insulation ensures excellent electrical isolation and long service life
- Solder-Lug Termination: Traditional solder connections for direct PCB mounting or panel wiring
- Rotary Selector Design: Smooth 30-degree or indexed detent operation for precise position selection
- Phenolic or Ceramic Construction: Options available depending on specific configuration requirements
Technical Specifications
- Manufacturer: Centralab
- Part Number: PA-6013
- Switch Type: Rotary Selector
- Pole Configuration: 4 Poles
- Position Configuration: 5 Positions
- Insulation Material: Ceramic (Steatite Grade L-5A)
- Termination Type: Solder Lugs
- Contact Type: AC/DC rated
- Indexing: 72-degree step (30-degree detent spacing)
- Application Class: Military/Industrial Control
Typical Applications
- Military test and measurement equipment panels
- Industrial control system selector switches
- Multi-function electronic instrumentation
- Signal routing in communications equipment
- Function selection in legacy avionics and navigation systems
- Equipment calibration and mode selection
- Replacement for worn or failed Centralab PA-series switches
Compatibility & Replacements
Compatible With
- Military standard MIL-S specifications for rotary switches
- Vintage and legacy industrial control systems
- Aerospace and telecommunications equipment using PA-series switches
- Custom control panels with 4-pole, 5-position switching requirements
- Standard 1/4-inch shaft mounting configurations
Replaces / Drop-In Replacement For
- Centralab PA-6013 (direct replacement)
- Other Centralab PA-series 4-pole switches requiring 5-position configuration
- Similar military-grade ceramic rotary switches in equivalent pin-outs
- Verify compatibility with your specific panel layout and wiring scheme before ordering
Works With
- Manual selector panels with rotary control mechanisms
- PCB-mounted applications using solder-lug connections
- Panel-mount chassis configurations with standard 3/8-inch or 1/2-inch bushing
- Legacy electronic systems using Centralab PA-series component libraries
- AC and DC control circuits up to specified voltage and current ratings
